SIL iSite Switch 5G
Model SIL iSite Switch 5GEAN 5060693982736
100 specifications
- Memory1000 MB
- SpeedWi-Fi 6E (802.11ax)
- TypePortable router
- Weight485 g
- ColourBlack
- Ethernet WANYes
Overview
- Memory
- 1000 MB
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- Portable router
- Weight
- 485 g
- Colour
- Black
- Ethernet WAN
- Yes
- Brand
- SilverNet
- Category
- Wireless Router
- Model
- SIL iSite Switch 5G
- Part number
- SIL iSite Switch 5G
- EAN / UPC
- 5060693982736
- Also known as
- SilverNet SIL iSite Switch 5G wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
Specifications
100 specifications in 17 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | Yes |
| WAN connection type | RJ-45 |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN data transfer rate (max) | 1800 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 600 Mbit/s |
| WLAN data transfer rate (second band) | 1200 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Auto-sensing | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| Multicast support | Yes |
| Port forwarding | Yes |
| Load balancing system | Yes |
| Automatic channel selection | Yes |
| Dynamic DNS (DDNS) | Yes |
| Policy-based routing | Yes |
| SSID-based VLAN assignment | Yes |
| Static route | Yes |
| Wireless Distribution System (WDS) bridge | Yes |
| VPN Passthrough | Yes |
| VPN support | OpenVPN IPSec LT2P PPTP |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | 5G |
| Dual SIM support | Yes |
| 4G standard | LTE |
| 5G standard | NR |
| SIM card type | MiniSIM |
| Short Message Service (SMS) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | Yes |
| Terminal block port | Yes |
| RS-485 ports | 1 |
| RS-232 ports | 1 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Bandwidth control | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| MIMO | Yes |
| Number of data streams | 2x2 |
Security
| Specification | Value |
|---|---|
| Security algorithms | AES, IPSec, WEP, WPA, WPA-AES, WPA-PSK, WPA2, WPA2-AES |
| Access Control List (ACL) | Yes |
| DDoS protection | Yes |
| Filtering | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| System event log | Yes |
| Network address translation (NAT) | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Portable router |
| Product colour | Black |
| Housing material | Metal |
| Wall mountable | Yes |
| International Protection (IP) code | IP30 |
| LED indicators | Activity, LAN, Link, Power, System, VPN, WLAN |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Power |
| AC adapter included | Yes |
| Antenna included | Yes |
| Quick start guide | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antenna connector type | SMA |
| Antennas quantity | 8 |
| Antenna direction type | Omni-directional |
| Detachable antenna(s) | Yes |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 2000 MHz |
| Processor cores | 4 |
| Internal memory | 1000 MB |
| Internal memory type | DDR4 |
| Flash memory | 1000 MB |
| Watch Dog function | Yes |
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC, USB |
| AC input voltage | 110 - 240 V |
| Power consumption (typical) | 7 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 85 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 115 mm |
| Height | 36.4 mm |
| Weight | 485 g |
| Width | 135 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 195 mm |
| Package depth | 340 mm |
| Package height | 55 mm |
| Package weight | 1.32 kg |
| Package type | Box |
| Number of products included | 1 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| UK Trade Tariff code | 85176200 |
| Warranty period | 2 year(s) |
