TP-Link Archer VR900

Archer VR900

Model Archer VR900Part no. ARCHER VR900 V3EAN 6935364097387

91 specifications

SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
ColourWhite
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Ethernet LAN (RJ-45) ports4

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Colour: White
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN (RJ-45) ports: 4

Brand: TP-Link
Category: Wireless Router
Model: Archer VR900
Part numbers: ARCHER VR900 V3, ARCHER VR900 V2
EAN / UPC: 6935364097387, 845973094478, 6935364097370, 6935364092818
Also known as: TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router

Specifications

91 specifications in 19 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	1300 Mbit/s
WLAN data transfer rate (second band)	600 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Dynamic DNS (DDNS)	Yes
Static route	Yes
VPN tunnels quantity	10
VPN Passthrough	Yes
VPN support	PPTP, L2TP, IPSec Passthrough

DSL features

Specification	Value
ADSL	Yes
ADSL2	Yes
ADSL2+	Yes
VDSL2	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Access Control List (ACL)	Yes
Guest access	Yes
DoS attack prevention	Yes
Filtering	Yes
MAC address filtering	Yes
IP address filtering	Yes
URL filtering	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Management protocols	SSL for TR-069, SNMP v1/2c
Data link protocols	IPv4, IPv6
Supported network protocols	ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC

Design

Specification	Value
Product type	Tabletop router
Product colour	White
Wall mountable	Yes
Indication light	Yes
LED indicators	Yes
On/off switch	Yes

Packaging content

Specification	Value
Cables included	DSL, LAN (RJ-45), Phone (RJ-11)
AC adapter included	Yes
Quick installation guide	Yes

Certificates

Specification	Value
Certification	CE, RCM, RoHS

Antenna

Specification	Value
Antenna design	External
Antenna connector type	RP-SMA
Antenna gain level (max)	3 dBi
Antennas quantity	3
Detachable antenna(s)	Yes
Transmit power	0 dBmW

Power

Specification	Value
Power source type	AC
Output voltage	12 V
Output current	2.5 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8
Linux operating systems supported	Yes
Mac operating systems supported	macOS

Weight & dimensions

Specification	Value
Depth	163.7 mm
Height	38.9 mm
Width	215.7 mm

Packaging data

Specification	Value
Package width	318 mm
Package depth	240 mm
Package height	71 mm
Package weight	1.27 kg

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Mobile network connection	Yes
Frequency band	2.4 & 5
Input current	3.3 A
Input voltage	12 V
Minimum system requirements	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 Cable / DSL Modem
Rack mounting	No
WLAN data transfer rates supported	600,1300 Mbit/s
xDSL connection	Yes
