Zyxel NBG6617 wireless router Gigabit Ethernet Dual-band (2.4 GHz

5 GHz) Black

Model NBG6617Part no. NBG6617-EU0101FEAN 4718937591015

71 specifications

SpeedWi-Fi 4 (802.11n)
TypeTabletop router
Weight329.2 g
ColourBlack
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Type: Tabletop router
Weight: 329.2 g
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)

Brand: Zyxel
Category: Wireless Router
Model: NBG6617
Part numbers: NBG6617-EU0101F, 7360
EAN / UPC: 4718937591015
Also known as: Zyxel NBG6617 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

71 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	867 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Auto MDI/MDI-X	Yes
Automatic channel selection	Yes

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	5
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Wake-on-LAN ready	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Guest access	Yes
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
Filtering	Yes
MAC address filtering	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IPv6, PPTP, L2TP, IPSec, FTP, SIP, H.323, RTSP, IRC, SNMP

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick start guide	Yes

Certificates

Specification	Value
Digital Living Network Alliance (DLNA) certified	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	2

Features

Specification	Value
Built-in processor	Yes
Processor frequency	600 MHz
Processor cores	4
Firmware upgradeable	Yes
Electromagnetic compatibility	CE, FCC
Safety	CE LVD

Power

Specification	Value
Power source type	DC
Output voltage	12 V
Output current	2 A
Power consumption (typical)	20 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95%
Storage temperature (T-T)	-30 - 70 °C

Weight & dimensions

Specification	Value
Depth	117 mm
Height	29.2 mm
Weight	329.2 g
Width	170 mm

Packaging data

Specification	Value
Package width	264 mm
Package depth	191 mm
Package height	57 mm
Package weight	736.6 g
