Zyxel Multy M1

Multy M1

Model Multy M1Part no. WSM20-GB0101FEAN 4718937629084

58 specifications

Memory256 MB
SpeedWi-Fi 6 (802.11ax)
TypeTabletop router
Weight254 g
ColourWhite
Ethernet WANYes

See all specifications

Overview

Memory: 256 MB
Speed: Wi-Fi 6 (802.11ax)
Type: Tabletop router
Weight: 254 g
Colour: White
Ethernet WAN: Yes

Brand: Zyxel
Category: Wireless Router
Model: Multy M1
Part numbers: WSM20-GB0101F, WSM20-EU0201F, WSM20-EU0101F, WSM20-GB0201F
EAN / UPC: 4718937629084, 4718937622726, 4718937622719, 4718937629091
Also known as: Zyxel Multy M1 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White

Specifications

58 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	1201 Mbit/s
Modulation	1024-QAM

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Auto MDI/MDI-X	Yes
Automatic channel selection	Yes
Dynamic DNS (DDNS)	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
DC-in jack	Yes

Management features

Specification	Value
Wi-Fi Multimedia (WMM)/(WME)	Yes
Reset button	Yes
MU-MIMO technology	Yes

Security

Specification	Value
Security algorithms	IPSec, SSID, WPA3-PSK, WPS
Guest access	Yes
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
MAC address filtering	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes

Design

Specification	Value
Product type	Tabletop router
Product colour	White
Wall mountable	Yes
LED indicators	Status

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes

Certificates

Specification	Value
Certification	CE-LVD, BSMI, CE, FCC, NCC

Antenna

Specification	Value
Antenna design	Internal
Antennas quantity	2

Features

Specification	Value
Built-in processor	Yes
Processor frequency	800 MHz
Processor cores	2
Internal memory	256 MB
Flash memory	128 MB
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	DC
Power consumption (typical)	15 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-30 - 70 °C

Weight & dimensions

Specification	Value
Depth	192 mm
Height	66 mm
Weight	254 g
Width	133 mm

Packaging data

Specification	Value
Package width	238 mm
Package depth	281 mm
Package height	151 mm
Package weight	1.72 kg
Number of products included	2 pc(s)

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
