Zyxel ARMOR Z2 NBG6817

Zyxel ARMOR Z2 NBG6817

Model ARMOR Z2 NBG6817Part no. NBG6817-EU0101FEAN 4059313121397

65 specifications
  • SpeedWi-Fi 4 (802.11n)
  • TypeTabletop router
  • Weight570 g
  • ColourBlack
  • Ethernet WANYes
  • Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
See all specifications

Overview

Speed
Wi-Fi 4 (802.11n)
Type
Tabletop router
Weight
570 g
Colour
Black
Ethernet WAN
Yes
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Brand
Zyxel
Model
ARMOR Z2 NBG6817
Part number
NBG6817-EU0101F
EAN / UPC
4059313121397, 4718937590667
Also known as
Zyxel ARMOR Z2 NBG6817 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

65 specifications in 16 groups

WAN connection

Ethernet WANYes
DSL WANNo
SIM card slotNo

Wireless LAN features

Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)2600 Mbit/s
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)800 Mbit/s
WLAN data transfer rate (second band)1733 Mbit/s

Network

Ethernet LANYes
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Auto MDI/MDI-XYes
Automatic channel selectionYes

Ports & interfaces

Ethernet LAN (RJ-45) ports5
USB portYes
USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Memory card slot(s)No
DC-in jackYes

Management features

Quality of Service (QoS) supportYes
Wake-on-LAN readyYes
Reset buttonYes
WPS push buttonYes

Security

Security algorithmsWPA, WPA-PSK, WPA2, WPA2-PSK, WPS
FirewallYes
Guest accessYes
Stateful Packet Inspection (SPI)Yes
FilteringYes
MAC address filteringYes
Network address translation (NAT)Yes

Protocols

DHCP clientYes
DHCP serverYes
Universal Plug and Play (UPnP)Yes

Design

Product typeTabletop router
Product colourBlack
Indication lightYes
LED indicatorsLAN, Power, System, WAN, WLAN
On/off switchYes

Packaging content

Cables includedLAN (RJ-45)
AC adapter includedYes
Quick start guideYes

Certificates

Digital Living Network Alliance (DLNA) certifiedYes

Antenna

Antenna designExternal
Antennas quantity4

Features

Built-in processorYes
Processor frequency1700 MHz
Processor cores2
Firmware upgradeableYes
Electromagnetic compatibilityCE, FCC, IC, BSMI
SafetyCE-LVD, BSMI

Power

Power source typeAC

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 95%
Storage temperature (T-T)-30 - 70 °C

Weight & dimensions

Depth168 mm
Height51 mm
Weight570 g
Width250 mm

Packaging data

Package width445 mm
Package depth258 mm
Package height60 mm
Package weight1.56 kg
