TP-Link TL-WR2543ND wireless router Gigabit Ethernet Black, Silver

TP-Link TL-WR2543ND wireless router Gigabit Ethernet Black, Silver

Model TL-WR2543NDEAN 8459730515636

47 specifications

SpeedWi-Fi 4 (802.11n)
ColourBlack, Silver
Ethernet WANYes
Ethernet LAN (RJ-45) ports4
Antenna connector typeRP-SMA
Operating relative humidity (H-H)10 - 90%

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Colour: Black, Silver
Ethernet WAN: Yes
Ethernet LAN (RJ-45) ports: 4
Antenna connector type: RP-SMA
Operating relative humidity (H-H): 10 - 90%

Brand: TP-Link
Category: Wireless Router
Model: TL-WR2543ND
Part number: TL-WR2543ND
EAN / UPC: 8459730515636, 745449855155, 845973051563, 5053313923417 +2 more
Also known as: TP-Link TL-WR2543ND wireless router Gigabit Ethernet Black, Silver

Specifications

47 specifications in 13 groups

WAN connection

Specification	Value
Ethernet WAN	Yes

Wireless LAN features

Specification	Value
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	450 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN support	PPTP, L2TP, IPsec
Receiver sensitivity	270M: -68dBm@10% 130M: -68dBm@10% 108M: -68dBm@10% 54M: -68dBm@10% 11M: -85dBm@8% 6M: -88dBm@10% 1M: -90dBm@8%

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
DC-in jack	Yes

Management features

Specification	Value
Quality of Service (QoS) support	Yes
Reset button	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Stateful Packet Inspection (SPI)	Yes
Filtering	Yes
MAC address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IP, Static IP, PPPoE, PPTP, L2TP, DynDns, Comexe, NO-IP

Design

Specification	Value
Product colour	Black, Silver
LED indicators	LAN, Power, WAN, WLAN, Yes

Packaging content

Specification	Value
Manual	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, FCC, RoHS

Antenna

Specification	Value
Antenna connector type	RP-SMA
Antennas quantity	3

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

Other features

Specification	Value
Bandwidth	2.4 GHz
Compatible operating systems	Windows 98SE Windows NT Windows 2000 Windows XP Windows Vista Windows 7 Mac OS NetWare UNIX Linux
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, 802.11a/b/g/n
Dimensions (WxDxH)	234 x 155 x 36 mm
Frequency range	2.4 - 2.4835GHz, 5.180 - 5.825GHz
Input current	1.5 A
Input voltage	12 V
Networking features	Gigabit Ethernet
Operating temperature (T-T)	32 - 104 °F
WLAN data transfer rates supported	11,54,150,300,450 Mbit/s
xDSL connection	No
