TP-Link N300 4G LTE Telephony WiFi Router

N300 4G LTE Telephony WiFi Router

Model TL-MR6500vPart no. TL-MR6500VEAN 1210002609319

75 specifications

SpeedWi-Fi 4 (802.11n)
TypeTabletop router
ColourBlack
Ethernet WANYes
Wi-Fi bandSingle-band (2.4 GHz)
Mobile network generation4G

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Type: Tabletop router
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Single-band (2.4 GHz)
Mobile network generation: 4G

Brand: TP-Link
Category: Wireless Router
Model: TL-MR6500v
Part number: TL-MR6500V
EAN / UPC: 1210002609319, 1210002609326, 6935364072353, 6935364072377
Also known as: TP-Link N300 4G LTE Telephony WiFi Router

Specifications

75 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	Yes
3G/4G USB modem compatibility	Yes
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	300 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Static route	Yes
Number of guest networks (2.4 GHz)	1
VPN server	PPTP VPN, OpenVPN
VPN tunnels quantity	10
VPN Passthrough	Yes

Mobile network

Specification	Value
Mobile network generation	4G
3G	Yes
4G	Yes
Dual SIM support	No
3G standards	DC-HSPA+, HSPA, HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
3G bands supported	900,2100 MHz
4G bands supported	800,900,1800,2100,2300,2500,2600 MHz
SIM card type	MicroSIM

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	No
RJ-11 ports quantity	1
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Wi-Fi Multimedia (WMM)/(WME)	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Firewall security	: DoS, SPI Firewall, IP and MAC Address Binding
Guest access	Yes
Parental control	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
VoIP protocols	SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.729AB, G.726

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
Wall mountable	Yes
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	2
Detachable antenna(s)	Yes

Power

Specification	Value
Power source type	DC
Output voltage	12 V
Output current	1 A

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

Weight & dimensions

Specification	Value
Depth	141 mm
Height	33.6 mm
Width	202 mm

Packaging data

Specification	Value
Package width	307 mm
Package depth	223 mm
Package height	70 mm
Package weight	640 g

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
