TP-Link TL-MR100 wireless router Fast Ethernet Single-band (2.4 GHz)

TL-MR100 wireless router Fast Ethernet Single-band (2.4 GHz)

4G Black

Model TL-MR100EAN 1210002609258

79 specifications

SpeedWi-Fi 4 (802.11n)
TypeTabletop router
Weight150 g
ColourBlack
Ethernet WANYes
Wi-Fi bandSingle-band (2.4 GHz)

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Type: Tabletop router
Weight: 150 g
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Single-band (2.4 GHz)

Brand: TP-Link
Category: Wireless Router
Model: TL-MR100
Part number: TL-MR100
EAN / UPC: 1210002609258, 1210002609265, 6935364088804, 6935364088811
Also known as: TP-Link TL-MR100 wireless router Fast Ethernet Single-band (2.4 GHz) 4G Black

Specifications

79 specifications in 19 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
SIM card slot	Yes
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Wireless radio	Yes
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
Receiver sensitivity	11g 54M: -74dBm 11n HT20: -71dBm 11n HT40: -67dBm

Mobile network

Specification	Value
Mobile network generation	4G
3G	Yes
4G	Yes
3G standards	HSPA, UMTS
4G standard	LTE-TDD & LTE-FDD
3G bands supported	850,900,2100 MHz
4G bands supported	800,900,1800,1900,2100,2300,2500,2600 MHz
SIM card type	MicroSIM

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	No
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Wi-Fi Multimedia (WMM)/(WME)	Yes
Quality of Service (QoS) support	Yes
Wireless statistics	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Guest access	Yes
Stateful Packet Inspection (SPI)	Yes
Schedule access	Yes
MAC address filtering	Yes
IP address filtering	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IPv4, IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes

Certificates

Specification	Value
Certification	CE, RoHS

Antenna

Specification	Value
Antenna design	External
Antenna connector type	N-type
Antennas quantity	2

Features

Specification	Value
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	DC
Output voltage	9 V
Output current	0.85 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	114 mm
Height	36 mm
Weight	150 g
Width	154 mm

Packaging data

Specification	Value
Package width	293 mm
Package depth	161 mm
Package height	66 mm
Package weight	480 g

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
