TP-Link TD-W9980 wireless router Gigabit Ethernet Dual-band (2.4 GHz

5 GHz) Black

Model TD-W9980EAN 5054484703976

58 specifications

SpeedWi-Fi 4 (802.11n)
ColourBlack
DSL WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
3GNo
Ethernet LAN (RJ-45) ports4

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Colour: Black
DSL WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
3G: No
Ethernet LAN (RJ-45) ports: 4

Brand: TP-Link
Category: Wireless Router
Model: TD-W9980
Part number: TD-W9980
EAN / UPC: 5054484703976, 845973061180, 4054843758822, 6935364061180 +1 more
Also known as: TP-Link TD-W9980 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

58 specifications in 18 groups

WAN connection

Specification	Value
DSL WAN	Yes

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	600 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Mobile network

Specification	Value
3G	No
4G	No

DSL features

Specification	Value
VDSL2	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Stateful Packet Inspection (SPI)	Yes
Filtering	Yes
MAC address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
Universal Plug and Play (UPnP)	Yes

Design

Specification	Value
Product colour	Black
LED indicators	Yes
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45), Phone (RJ-11)
AC adapter included	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	Internal & external
Antenna connector type	RP-SMA
Antenna gain level (max)	5 dBi
Antennas quantity	5
Detachable antenna(s)	Yes

Features

Specification	Value
Firmware upgradeable	Yes

Power

Specification	Value
Power supply	18 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	160.6 mm
Height	32.5 mm
Width	243 mm

Other features

Specification	Value
Mobile network connection	No
Frequency band	2.4 & 5
Input current	1.5 A
Rack mounting	No
Supported protocols	ATM Forum UNI3.1/4.0 PPP over ATM (RFC 2364) PPP over Ethernet (RFC2516) IPoA (RFC1577/2225) PVC - Up to 8 PVCs
USB ports quantity	2
USB version	2.0
WLAN data transfer rates supported	300,600 Mbit/s
xDSL connection	Yes
