TP-Link TD-W9977 wireless router Gigabit Ethernet Single-band (2.4 GHz) Black

TP-Link TD-W9977 wireless router Gigabit Ethernet Single-band (2.4 GHz) Black

Model TD-W9977EAN 6935364096830

70 specifications

ProcessorBroadcom
SpeedWi-Fi 4 (802.11n)
TypeTabletop router
ColourBlack
Ethernet WANYes
Wi-Fi bandSingle-band (2.4 GHz)

See all specifications

Overview

Processor: Broadcom
Speed: Wi-Fi 4 (802.11n)
Type: Tabletop router
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Single-band (2.4 GHz)

Brand: TP-Link
Category: Wireless Router
Model: TD-W9977
Part number: TD-W9977
EAN / UPC: 6935364096830
Also known as: TP-Link TD-W9977 wireless router Gigabit Ethernet Single-band (2.4 GHz) Black

Specifications

70 specifications in 18 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	No

Wireless LAN features

Specification	Value
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	10
VPN support	PPTP, L2TP, IPSec

Mobile network

Specification	Value
3G	No
4G	No

DSL features

Specification	Value
ADSL	Yes
ADSL2	Yes
ADSL2+	Yes
VDSL	Yes
VDSL2	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	No
RJ-11 ports quantity	1
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Firewall	Yes
Filtering	Yes
MAC address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Routing protocols	RIP-1, RIP-2
Management protocols	SNMP v1/2
Supported network protocols	IPv4/IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
On/off switch	Yes

Packaging content

Specification	Value
Cables included	DSL, LAN (RJ-45)
AC adapter included	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, RoHS, RCM

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	5 dBi
Antennas quantity	3

Features

Specification	Value
Built-in processor	Yes
Processor model	Broadcom
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	AC
Output voltage	12 V
Output current	1 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Mac compatibility	Yes

Weight & dimensions

Specification	Value
Depth	167.5 mm
Height	32.7 mm
Width	243.5 mm
