TP-Link TD-W8961NB wireless router Fast Ethernet

TP-Link TD-W8961NB wireless router Fast Ethernet

Model TD-W8961NBEAN 6935364060503

52 specifications
  • SpeedWi-Fi 4 (802.11n)
  • ConnectivityRJ-45
  • Ethernet WANYes
  • Ethernet LAN (RJ-45) ports4
  • LED indicatorsLAN, WAN
  • Antenna gain level (max)6 dBi
See all specifications

Overview

Speed
Wi-Fi 4 (802.11n)
Connectivity
RJ-45
Ethernet WAN
Yes
Ethernet LAN (RJ-45) ports
4
LED indicators
LAN, WAN
Antenna gain level (max)
6 dBi
Brand
TP-Link
Model
TD-W8961NB
Part number
TD-W8961NB
EAN / UPC
6935364060503, 6935364090418
Also known as
TP-Link TD-W8961NB wireless router Fast Ethernet

Specifications

52 specifications in 13 groups

WAN connection

Ethernet WANYes

Wireless LAN features

Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3u
Full duplexYes

DSL features

ADSL2+Yes
DSL specificationITU-T G.992.1, 992.2, 994.1, 995.1, 992.3, 992.4

Ports & interfaces

Ethernet LAN (RJ-45) ports4
RJ-11 ports quantity1
DC-in jackYes

Management features

Web-based managementYes
Quality of Service (QoS) supportYes

Security

Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Stateful Packet Inspection (SPI)Yes
FilteringYes
MAC address filteringYes
DMZ supportYes
Network address translation (NAT)Yes

Protocols

DHCP clientYes
DHCP serverYes
Management protocolsHTTP, SSL, SNMP v1/2c, SNMP, CWMP

Design

LED indicatorsLAN, WAN

Packaging content

Cables includedLAN (RJ-45), Phone (RJ-11)
AC adapter includedYes
ManualYes
Quick start guideYes

Antenna

Antenna gain level (max)6 dBi
Antennas quantity2

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C

Other features

Bandwidth2.4835 GHz
Compatible operating systemsWindows 98SE/NT/2000/XP/Vista/7, Mac OS, netWare, Unix, Linux
Data transfer rate100 Mbit/s
Dimensions (WxDxH)174 x 120 x 28.8 mm
Filtering descriptionMAC, IP, Packet, Application, URL
Frequency range2.400 - 2.4835GHz
Input current1 A
Input voltage12 V
InterfaceRJ-45
Networking featuresFast Ethernet
Operating temperature (T-T)32 - 104 °F
Power supply typeDC
ThroughputPPTP, L2TP, IPSec
WLAN data transfer rates supported300 Mbit/s
xDSL connectionYes
