TP-Link TD-W8950N wireless router Fast Ethernet Blue, White

Model TD-W8950NEAN 6935364061241

58 specifications

SpeedWi-Fi 4 (802.11n)
ColourBlue, White
Ethernet WANYes
3GNo
Ethernet LAN (RJ-45) ports4
Antenna designExternal

See all specifications

Overview

Speed: Wi-Fi 4 (802.11n)
Colour: Blue, White
Ethernet WAN: Yes
3G: No
Ethernet LAN (RJ-45) ports: 4
Antenna design: External

Brand: TP-Link
Category: Wireless Router
Model: TD-W8950N
Part number: TD-W8950N
EAN / UPC: 6935364061241
Also known as: TP-Link TD-W8950N wireless router Fast Ethernet Blue, White

Specifications

58 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes

Wireless LAN features

Specification	Value
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN support	PPTP, L2TP, IPSec

Mobile network

Specification	Value
3G	No
4G	No

DSL features

Specification	Value
ADSL2+	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
Filtering	Yes
MAC address filtering	Yes
IP address filtering	Yes
URL filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
Universal Plug and Play (UPnP)	Yes

Design

Specification	Value
Product colour	Blue, White
Housing material	Plastic
LED indicators	Yes
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45), Phone (RJ-11)
AC adapter included	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	5 dBi
Antennas quantity	1

Power

Specification	Value
Output voltage	9 V

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	125 mm
Height	36 mm
Width	181 mm

Other features

Specification	Value
Mobile network connection	No
Filtering description	MAC, IP, URL, DoS
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
Input current	0.85 A
Rack mounting	No
WLAN data transfer rates supported	150 Mbit/s
xDSL connection	Yes
