EB810V wireless router 2.5 Gigabit Ethernet Tri-band (2.4 GHz
5 GHz / 6 GHz)
Model EB810VPart no. 1014605
40 specifications
- SpeedWi-Fi 7 (802.11be)
- TypeTabletop router
- Ethernet WANYes
- Ethernet LAN (RJ-45) ports5
- Antenna designInternal
- Power source typeDC
Overview
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Tabletop router
- Ethernet WAN
- Yes
- Ethernet LAN (RJ-45) ports
- 5
- Antenna design
- Internal
- Power source type
- DC
- Brand
- TP-Link
- Category
- Wireless Router
- Model
- EB810V
- Part number
- 1014605
- Also known as
- TP-Link EB810V wireless router 2.5 Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Specifications
40 specifications in 13 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| SIM card slot | No |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (first band) | 1376 Mbit/s |
| WLAN data transfer rate (second band) | 5760 Mbit/s |
| WLAN data transfer rate (third band) | 11520 Mbit/s |
| Modulation | 4096-QAM |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN data rates | 1000,2500,10000 Mbit/s |
| Port forwarding | Yes |
| VPN support | PPTP, OpenVPN, IPSec |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| USB port | Yes |
| RJ-11 ports quantity | 2 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Bandwidth control | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| WPS push button | Yes |
| MIMO | Yes |
| MU-MIMO technology | Yes |
Security
| Specification | Value |
|---|---|
| Firewall | Yes |
| Firewall security | DoS, SPI Firewall, IP & MAC Address Binding |
Design
| Specification | Value |
|---|---|
| Product type | Tabletop router |
Certificates
| Specification | Value |
|---|---|
| Certification | CE |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 5 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 262.5 mm |
| Height | 302 mm |
| Width | 96 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
