TP-Link Archer C6 wireless router Fast Ethernet Dual-band (2.4 GHz

Archer C6 wireless router Fast Ethernet Dual-band (2.4 GHz

5 GHz) White

Model C6Part no. ARCHER C6EAN 6935364088903

75 specifications

SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
ColourWhite
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
3GNo

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Colour: White
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
3G: No

Brand: TP-Link
Category: Wireless Router
Model: C6
Part number: ARCHER C6
EAN / UPC: 6935364088903, 840460602105, 845973088903, 1210002606523 +2 more
Also known as: TP-Link Archer C6 wireless router Fast Ethernet Dual-band (2.4 GHz / 5 GHz) White

Specifications

75 specifications in 18 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	450 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding	Yes
VPN Passthrough	Yes
VPN support	PPTP, L2TP, IPSec
Receiver sensitivity	5GHz: 11a 54M: -76dBm 11ac VHT20 MCS8: -70dBm 11ac VHT40 MCS9: -65.5dBm 11ac VHT80 MCS9: -61.5dBm 2.4G: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71dBm

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	5
USB port	No
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Guest access	Yes
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
Filtering	Yes
MAC address filtering	Yes
IP address filtering	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
VoIP protocols	IPv4, IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	White
Indication light	Yes
LED indicators	LAN, Power, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Manual	Yes
Quick installation guide	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	5
Transmit power	CE: <20dBm(2.4GHz), <23dBm(5GHz)

Power

Specification	Value
Power source type	AC
Output voltage	12 V
Output current	1 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows
Linux operating systems supported	Yes
Mac operating systems supported	macOS
Mac compatibility	Yes

Weight & dimensions

Specification	Value
Depth	117 mm
Height	32 mm
Width	215 mm

Packaging data

Specification	Value
Package width	350 mm
Package depth	240 mm
Package height	82 mm
Package weight	870 g
Package type	Box

Logistics data

Specification	Value
Harmonized System (HS) code	85176990

Other features

Specification	Value
Maximum data transfer rate	1 Mbit/s
