Archer MX700
Model Archer MX700Part no. ARCHER MX700EAN 1210002608022
62 specifications
- SpeedWi-Fi 6 (802.11ax)
- TypeRack/wall router
- ColourWhite
- Ethernet WANYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Mobile network generation4G
Overview
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Rack/wall router
- Colour
- White
- Ethernet WAN
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Mobile network generation
- 4G
- Brand
- TP-Link
- Category
- Wireless Router
- Model
- Archer MX700
- Part number
- ARCHER MX700
- EAN / UPC
- 1210002608022, 1210002608039, 8885020621723
- Also known as
- TP-Link Archer MX700 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) 4G White
Specifications
62 specifications in 18 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 1201 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| WLAN data transfer rate (second band) | 1201 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Port triggering | Yes |
| Dynamic DNS (DDNS) | Yes |
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| Receiver sensitivity | 5 GHz: 11a 54M: -77 dBm 11ax HE20:-64 dBm 11ax HE40: -61 dBm 11ax HE80:-59 dBm 11ac VHT20: -69 dBm 11ac VHT40: -66 dBm 11ac VHT80 : -63 dBm 11n HT20: -74 dBm 11n HT40: -71 dBm 2.4 GHz: 11g 54M: -78 dBm 11n HT20: -75 dBm 11n HT40: -72 dBm |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | 4G |
| 4G standard | LTE-TDD & LTE-FDD |
| 3G bands supported | 850,900,2100 MHz |
| SIM card type | NanoSIM |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | No |
| DC-in jack | Yes |
Management features
| Specification | Value |
|---|---|
| Bandwidth control | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| MU-MIMO technology | Yes |
| Cloud-managed | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Personal |
| Firewall security | IPv4 SPI Firewall, ALG, IP and MAC Address Binding, Access Control |
| Schedule access | Yes |
| System event log | Yes |
| DMZ support | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Supported network protocols | IPv4, IPv6 |
Design
| Specification | Value |
|---|---|
| Product type | Rack/wall router |
| Product colour | White |
| Wall mountable | Yes |
| On/off switch | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Quick installation guide | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
| Antennas quantity | 6 |
Features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 148.6 mm |
| Height | 67.5 mm |
| Width | 199.7 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
