TP-Link Archer D7b

TP-Link Archer D7b

Model Archer D7bPart no. ARCHER D7BEAN 6935364080037

61 specifications
  • SpeedWi-Fi 5 (802.11ac)
  • ColourBlack
  • Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
  • Ethernet LANYes
  • Ethernet LAN (RJ-45) ports4
  • Antenna designExternal
See all specifications

Overview

Speed
Wi-Fi 5 (802.11ac)
Colour
Black
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
4
Antenna design
External
Brand
TP-Link
Model
Archer D7b
Part numbers
ARCHER D7B, ARCHER D7B (DE)
EAN / UPC
6935364080037, 8944467765053, 845973080037
Also known as
TP-Link Archer D7b wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

61 specifications in 16 groups

Wireless LAN features

Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Ethernet LANYes
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ad, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity10
VPN supportPPTP, L2TP, IPSec

DSL features

DSL specificationANSI T1.413, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.994.1, ITU-T G.995.1, ITU-T G.992.3, ITU-T G.992.4, ITU-T G.992.5

Ports & interfaces

Ethernet LAN (RJ-45) ports4
RJ-11 ports quantity1
DC-in jackYes

Management features

Web-based managementYes
Quality of Service (QoS) supportYes
Reset buttonYes

Security

Security algorithms128-bit WEP, 64-bit WEP, WDS, WPA, WPA-PSK, WPA2, WPA2-PSK
Authentication methodUNI3.1/4.0, RFC 2364, PPPoE, IPoA, MER\IPoE
FirewallYes
FilteringYes
MAC address filteringYes
URL filteringYes
DMZ supportYes

Protocols

DHCP clientYes
DHCP serverYes
Universal Plug and Play (UPnP)Yes
Switching protocolsDNS, DDNS
Routing protocolsRIP-1, RIP-2
Management protocolsSSL, SNMP v1/2c, IGMP V1/V2/V3

Design

Product colourBlack
On/off switchYes

Packaging content

Cables includedLAN (RJ-45), Phone (RJ-11)
AC adapter includedYes
Quick start guideYes

Certificates

CertificationCE, FCC, RMC, RoHS

Antenna

Antenna designExternal
Antenna gain level (max)3 dBi
Antennas quantity3
Detachable antenna(s)Yes

Features

Firmware upgradeableYes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C

System requirements

Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supportedYes
Mac operating systems supportedYes

Weight & dimensions

Depth160 mm
Height37 mm
Width229 mm

Other features

Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
Filtering descriptionMAC, IP, URL
Frequency band2.4 & 5
Input current2.5 A
Rack mountingNo
USB ports quantity2
USB version2.0
WLAN data transfer rates supported450,1300 Mbit/s
xDSL connectionYes
