TP-Link Archer D7

TP-Link Archer D7

Model Archer D7Part no. ARCHER D7EAN 6935364050948

60 specifications

SpeedWi-Fi 5 (802.11ac)
ColourBlack
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Ethernet LANYes
Ethernet LAN (RJ-45) ports4
Antenna designExternal

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Colour: Black
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 4
Antenna design: External

Brand: TP-Link
Category: Wireless Router
Model: Archer D7
Part number: ARCHER D7
EAN / UPC: 6935364050948, 801947281763, 804066792271, 804904085954 +11 more
Also known as: TP-Link Archer D7 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

60 specifications in 16 groups

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ad, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
VPN support	PPTP, L2TP, IPSec

DSL features

Specification	Value
DSL specification	ANSI T1.413, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.994.1, ITU-T G.995.1, ITU-T G.992.3, ITU-T G.992.4, ITU-T G.992.5

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WDS, WPA, WPA-PSK, WPA2, WPA2-PSK
Authentication method	UNI3.1/4.0, RFC 2364, PPPoE, IPoA, MER\IPoE
Firewall	Yes
Filtering	Yes
MAC address filtering	Yes
URL filtering	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Switching protocols	DNS, DDNS
Routing protocols	RIP-1, RIP-2
Management protocols	SSL, SNMP v1/2c, IGMP V1/V2/V3

Design

Specification	Value
Product colour	Black
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45), Phone (RJ-11)
AC adapter included	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, FCC, RMC, RoHS

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	3 dBi
Antennas quantity	3
Detachable antenna(s)	Yes

Features

Specification	Value
Firmware upgradeable	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	160.6 mm
Height	32.5 mm
Width	243 mm

Other features

Specification	Value
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
Filtering description	MAC, IP, URL
Frequency band	2.4 & 5
Input current	2.5 A
Rack mounting	No
USB ports quantity	2
USB version	2.0
WLAN data transfer rates supported	450,1300 Mbit/s
xDSL connection	Yes
