TP-Link Archer C5400X

TP-Link Archer C5400X

Model Archer C5400XPart no. ARCHER C5400X V1EAN 6935364081454

85 specifications
  • SpeedWi-Fi 5 (802.11ac)
  • TypeTabletop router
  • ColourBlack, Red
  • Ethernet WANYes
  • 3GNo
  • Ethernet LAN (RJ-45) ports8
See all specifications

Overview

Speed
Wi-Fi 5 (802.11ac)
Type
Tabletop router
Colour
Black, Red
Ethernet WAN
Yes
3G
No
Ethernet LAN (RJ-45) ports
8
Brand
TP-Link
Model
Archer C5400X
Part numbers
ARCHER C5400X V1, ARCHER C5400X
EAN / UPC
6935364081454, 845973081454, 6935364082222
Also known as
TP-Link AC5400 MU-MIMO Tri-Band Gaming Router

Specifications

85 specifications in 18 groups

WAN connection

Ethernet WANYes
DSL WANNo
SIM card slotNo
3G/4G USB modem compatibilityNo
WAN connection typeRJ-45

Wireless LAN features

Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2167 Mbit/s
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)2167 Mbit/s
WLAN data transfer rate (second band)2167 Mbit/s
WLAN data transfer rate (third band)1000 Mbit/s

Network

Ethernet LANYes
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Port forwardingYes
Dynamic DNS (DDNS)Yes
Number of guest networks (2.4 GHz)1
Number of guest networks (5 GHz)2
Support Samba (storage)Yes
USB sharingYes
Wireless Distribution System (WDS) bridgeYes
Built-in FTP serverYes
Media serverYes
Receiver sensitivity5GHz: 11a 6Mbps: -94dBm, 11a 54Mbps: -76dBm 11ac VHT20_MCS0: -96dBm, 11ac VHT20_MCS11: -64dBm 11ac VHT40_MCS0: -93dBm, 11ac VHT40_MCS11: -61dBm 11ac VHT80_MCS0: -89dBm, 11ac VHT80_MCS11: -58dBm, 2.4GHz: 11g 6Mbps: -97dBm, 11g 54Mbps: -79dBm 11n HT20_MCS0: -98dBm, 11n HT20_MCS7: -77dBm 11ac VHT20_MCS

Mobile network

3GNo
4GNo

Ports & interfaces

Ethernet LAN (RJ-45) ports8
USB portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Memory card slot(s)No
DC-in jackYes

Management features

Web-based managementYes
Wi-Fi Multimedia (WMM)/(WME)Yes
Quality of Service (QoS) supportYes
Reset buttonYes
WPS push buttonYes

Security

Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
FirewallYes
Access Control List (ACL)Yes
Guest accessYes
Stateful Packet Inspection (SPI)Yes
Parental controlYes
DMZ supportYes
Network address translation (NAT)Yes

Protocols

DHCP clientYes
DHCP serverYes
Supported network protocolsIPv4, IPv6

Design

Product typeTabletop router
Product colourBlack, Red
Wall mountableYes
LED indicatorsPower
On/off switchYes

Packaging content

Cables includedLAN (RJ-45)
AC adapter includedYes
Quick installation guideYes

Certificates

CertificationFCC, CE, DFS, VCCI, JRF, JPA, RoHS

Antenna

Antenna designExternal
Antennas quantity8
Detachable antenna(s)Yes
Transmit power20 dBmW

Features

Built-in processorYes
Processor frequency1800 MHz
Processor cores4
Firmware upgradeableYes

Power

Power source typeDC
Output voltage12 V
Output current5 A

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C

System requirements

Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supportedYes
Mac operating systems supportedmacOS
Mac compatibilityYes

Weight & dimensions

Depth240.5 mm
Height55.3 mm
Width240.5 mm

Packaging data

Package width365 mm
Package depth290 mm
Package height120 mm
Package weight2.69 kg
