TP-Link Archer C3200

Archer C3200

Model Archer C3200Part no. ARCHER C3200EAN 6935364092276

70 specifications

SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
ColourBlack
Ethernet WANYes
3GNo
Ethernet LAN (RJ-45) ports4

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Colour: Black
Ethernet WAN: Yes
3G: No
Ethernet LAN (RJ-45) ports: 4

Brand: TP-Link
Category: Wireless Router
Model: Archer C3200
Part number: ARCHER C3200
EAN / UPC: 6935364092276, 845973092276, 857989006123, 6935364092283 +1 more
Also known as: TP-Link Archer C3200 wireless router Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 5 GHz) Black

Specifications

70 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	No

Wireless LAN features

Specification	Value
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	1300 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
WLAN data transfer rate (third band)	600 Mbit/s
Number of WLAN connections (max)	4

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
VPN tunnels quantity	10
VPN support	PPTP, L2TP, IPSec
Receiver sensitivity	5GHz: 11a 6Mbps: -94dBm 11a 54Mbps: -76dBm 11ac HT20: -68dBm 11ac HT40: -64dBm 11ac HT80: -60dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -73dBm 11n HT40: -71dBm

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Firewall security	Domain Filter, IP Address Binding, MAC Address Binding
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
Filtering	Yes
IP address filtering	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
VoIP protocols	IPv4, IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
Housing material	Plastic
Wall mountable	Yes
Indication light	Yes
LED indicators	LAN, Link, Power, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Manual	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, FCC, RoHS

Antenna

Specification	Value
Antenna design	External
Antennas quantity	6

Power

Specification	Value
Power source type	AC
Output voltage	12 V
Output current	5 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	200 mm
Height	39 mm
Width	200 mm

Packaging data

Specification	Value
Package type	Box
