Archer C20 W
Model Archer C20 WPart no. ARCHER C20 WEAN 840460606387
50 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypeTabletop router
- ColourSilver
- Ethernet WANYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- 3GNo
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Tabletop router
- Colour
- Silver
- Ethernet WAN
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- 3G
- No
- Brand
- TP-Link
- Category
- Wireless Router
- Model
- Archer C20 W
- Part number
- ARCHER C20 W
- EAN / UPC
- 840460606387, 845973086480
- Also known as
- TP-Link Archer C20 W wireless router Fast Ethernet Dual-band (2.4 GHz / 5 GHz) Silver
Specifications
50 specifications in 15 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 433 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| WLAN data transfer rate (second band) | 433 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Dynamic DNS (DDNS) | Yes |
| VPN Passthrough | Yes |
| VPN support | PPTP, L2TP, IPSec |
Mobile network
| Specification | Value |
|---|---|
| 3G | No |
| 4G | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| USB port | No |
| Memory card slot(s) | No |
Management features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall | Yes |
| Firewall security | DoS, SPI Firewall, IP Address Filter / Domain Filter, IP Address Link, MAC |
| Stateful Packet Inspection (SPI) | Yes |
| Filtering | Yes |
| MAC address filtering | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Tabletop router |
| Product colour | Silver |
| On/off switch | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| Manual | Yes |
| Quick installation guide | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, RoHS |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antennas quantity | 3 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Output voltage | 9 V |
| Output current | 0.6 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 144 mm |
| Height | 35 mm |
| Width | 230 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 357 mm |
| Package depth | 223 mm |
| Package height | 68 mm |
| Package type | Box |
| Number of products included | 1 pc(s) |
