TP-Link Archer C20

TP-Link Archer C20

Model Archer C20Part no. ARCHER C20 V2EAN 6935364097448

50 specifications
  • SpeedWi-Fi 5 (802.11ac)
  • Ethernet WANYes
  • Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
  • 3GNo
  • Ethernet LAN (RJ-45) ports5
  • Antenna designExternal
See all specifications

Overview

Speed
Wi-Fi 5 (802.11ac)
Ethernet WAN
Yes
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
3G
No
Ethernet LAN (RJ-45) ports
5
Antenna design
External
Brand
TP-Link
Model
Archer C20
Part number
ARCHER C20 V2
EAN / UPC
6935364097448
Also known as
TP-Link Archer C20 wireless router Fast Ethernet Dual-band (2.4 GHz / 5 GHz)

Specifications

50 specifications in 15 groups

WAN connection

Ethernet WANYes
DSL WANNo
SIM card slotNo
3G/4G USB modem compatibilityNo

Wireless LAN features

Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)433 Mbit/s
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)433 Mbit/s

Network

Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
VPN supportPPTP, L2TP, IPSec

Mobile network

3GNo
4GNo

Ports & interfaces

Ethernet LAN (RJ-45) ports5
USB portYes
USB 2.0 ports quantity1
DC-in jackYes

Management features

Quality of Service (QoS) supportYes
Reset buttonYes
WPS push buttonYes

Security

Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
FirewallYes
Port-based Network Access Control (PNAC)Yes
DoS attack preventionYes
FilteringYes
MAC address filteringYes
DMZ supportYes

Protocols

Universal Plug and Play (UPnP)Yes

Design

On/off switchYes

Certificates

CertificationCE, FCC, RoHS

Antenna

Antenna designExternal
Antennas quantity2
Detachable antenna(s)No

Power

Power source typeDC
Output voltage12 V
Output current1 A

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac compatibilityYes

Weight & dimensions

Depth144 mm
Height35 mm
Width230 mm
