TP-Link Archer C1200

TP-Link Archer C1200

Model Archer C1200Part no. ARCHER C1200EAN 6935364098414

71 specifications

SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
ColourBlack
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
3GNo

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
3G: No

Brand: TP-Link
Category: Wireless Router
Model: Archer C1200
Part numbers: ARCHER C1200, ARCHER C1200 V2
EAN / UPC: 6935364098414, 6935364095895, 6935364096052, 845973096052
Also known as: TP-Link AC1200 Wireless Dual Band Gigabit WiFi Router

Specifications

71 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding	Yes
VPN support	Open VPN, PPTP VPN, PPTP, L2TP, IPSec
Receiver sensitivity	5GHz: 11a 54M: -76dBm 11ac HT20: -68dBm 11ac HT40: -65dBm 11ac HT80 : -62dBm 11n HT20: -74dBm 11n HT40: -71dBm 2.4G: 11g 54M: -75dBm 11n HT20: -72dBm 11n HT40: -69dBm

Mobile network

Specification	Value
3G	No
4G	No
5G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 2.0 ports quantity	2
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Yes
Firewall security	Domain Filter, IP Address Binding, MAC Address Binding
Guest access	Yes
Stateful Packet Inspection (SPI)	Yes
DoS attack prevention	Yes
Filtering	Yes
IP address filtering	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IPv4/IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
Wall mountable	Yes
Indication light	Yes
LED indicators	LAN, Power, Status, WAN, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, RoHS

Antenna

Specification	Value
Antenna design	External
Antennas quantity	3
Transmit power	CE: <20dBm(2.4GHz), <23dBm(5GHz)

Power

Specification	Value
Power source type	DC
Output voltage	12 V
Output current	1 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

Weight & dimensions

Specification	Value
Depth	168 mm
Height	33 mm
Width	243 mm

Packaging data

Specification	Value
Package width	330 mm
Package depth	240 mm
Package height	80 mm
Package weight	970 g
Package type	Box
