TP-Link Archer AX55

Archer AX55

Model Archer AX55Part no. ARCHER AX55EAN 840030703041

74 specifications

Memory512 MB
SpeedWi-Fi 6 (802.11ax)
TypeTabletop router
ColourBlack
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)

See all specifications

Overview

Memory: 512 MB
Speed: Wi-Fi 6 (802.11ax)
Type: Tabletop router
Colour: Black
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)

Brand: TP-Link
Category: Wireless Router
Model: Archer AX55
Part number: ARCHER AX55
EAN / UPC: 840030703041, 4897098682678, 4897098683040
Also known as: TP-Link Archer AX3000 Dual Band Gigabit Wi-Fi 6 Router

Specifications

74 specifications in 19 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2976 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Number of guest networks (2.4 GHz)	1
Number of guest networks (5 GHz)	1
Built-in FTP server	Yes
Media server	Yes
VPN server	OpenVPN, PPTP

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1

Management features

Specification	Value
Quality of Service (QoS) support	Yes
Reset button	Yes
Intelligent Mesh technology	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Firewall	Yes
DDoS protection	Yes
DoS attack prevention	Yes
Parental control	Yes
Filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	IPv4, IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes

Certificates

Specification	Value
Compliance certificates	RoHS, Federal Communications Commission (FCC), CE

Sustainability

Specification	Value
Sustainability compliance	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	4
Detachable antenna(s)	No

Features

Specification	Value
Built-in processor	Yes
Processor cores	2
Internal memory	512 MB
Works with Amazon Alexa	Yes
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	AC
Output voltage	12 V
Output current	2 A
External power adapter	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C

System requirements

Specification	Value
Browser supported	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+

Weight & dimensions

Specification	Value
Depth	134.5 mm
Height	41 mm
Width	261.1 mm

Packaging data

Specification	Value
Package width	330 mm
Package depth	240 mm
Package height	73 mm
Package weight	940 g
Number of products included	1 pc(s)

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
