TP-Link Archer AC1600

Archer AC1600

Model Archer AC1600Part no. ARCHER VR600VEAN 6935364081980

73 specifications

SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
ColourBlack, Silver
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Mobile network generation4G

See all specifications

Overview

Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Colour: Black, Silver
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Mobile network generation: 4G

Brand: TP-Link
Category: Wireless Router
Model: Archer AC1600
Part number: ARCHER VR600V
EAN / UPC: 6935364081980, 6935364095437
Also known as: TP-Link Archer AC1600 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) 4G Black, Silver

Specifications

73 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	Yes
3G/4G USB modem compatibility	Yes

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1600 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	1300 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Port forwarding	Yes
VPN tunnels quantity	10
VPN support	PPTP, L2TP, IPSec Passthrough

Mobile network

Specification	Value
Mobile network generation	4G
3G	Yes
4G	Yes

DSL features

Specification	Value
ADSL	Yes
ADSL2	Yes
ADSL2+	Yes
VDSL	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 2.0 ports quantity	2
RJ-11 ports quantity	3
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2
Firewall	Yes
Guest access	Yes
Filtering	Yes
MAC address filtering	Yes
IP address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes
NAT functionality	NAT firewall

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
VoIP protocols	SIP (RFC3261) ITU-T G.711MuLaw / G.711ALaw / G.726_32 / G.729a / b / G.722
Supported network protocols	IPv4, IPv6

Design

Specification	Value
Product type	Tabletop router
Product colour	Black, Silver
Indication light	Yes
On/off switch	Yes

Packaging content

Specification	Value
AC adapter included	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	23 dBi
Antennas quantity	3
Detachable antenna(s)	Yes

Features

Specification	Value
Plug and Play	Yes

Power

Specification	Value
Power source type	AC, PoE
Output voltage	12 V
Output current	2.5 A
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C

System requirements

Specification	Value
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes

Weight & dimensions

Specification	Value
Depth	163.8 mm
Height	38.5 mm
Width	215.8 mm
