TP-Link Archer A7

TP-Link Archer A7

Model Archer A7Part no. ARCHER A7 V5EAN 845973083861

78 specifications
  • SpeedWi-Fi 5 (802.11ac)
  • TypeTabletop router
  • ColourBlack
  • Ethernet WANYes
  • Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
  • Ethernet LAN (RJ-45) ports4
See all specifications

Overview

Speed
Wi-Fi 5 (802.11ac)
Type
Tabletop router
Colour
Black
Ethernet WAN
Yes
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN (RJ-45) ports
4
Brand
TP-Link
Model
Archer A7
Part numbers
ARCHER A7 V5, ARCHER A7
EAN / UPC
845973083861, 6935364070236, 6935364083861
Also known as
TP-Link AC1750 Wireless Dual Band Gigabit WiFi Router

Specifications

78 specifications in 16 groups

WAN connection

Ethernet WANYes
DSL WANNo
SIM card slotNo
3G/4G USB modem compatibilityNo
WAN connection typeRJ-45

Wireless LAN features

Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)450 Mbit/s
WLAN data transfer rate (second band)1300 Mbit/s

Network

Ethernet LANYes
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Port forwardingYes
Dynamic DNS (DDNS)Yes
Number of guest networks (2.4 GHz)1
Number of guest networks (5 GHz)1
Support Samba (storage)Yes
USB sharingYes
Wireless Distribution System (WDS) bridgeYes
Built-in FTP serverYes
Media serverYes
VPN serverPPTP VPN and OpenVPN
VPN PassthroughYes
VPN supportPPTP, L2TP, IPSec
Receiver sensitivity5GHz: 11a 6Mbps: -93dBm, 11a 54Mbps: -76dBm 11ac HT20 mcs8 : -68dBm, 11ac HT40 mcs9: -64dBm 11ac HT80 mcs9: -61dBm 2.4GHz: 11g 54Mbps: -77dBm 11n HT20 mcs7: -74dBm, 11n HT40 mcs7: -72dBm

Ports & interfaces

Ethernet LAN (RJ-45) ports4
USB portYes
USB 2.0 ports quantity1
Memory card slot(s)No
DC-in jackYes

Management features

Bandwidth controlYes
Wi-Fi Multimedia (WMM)/(WME)Yes
Quality of Service (QoS) supportYes
Reset buttonYes
WPS push buttonYes

Security

Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
FirewallYes
Firewall securityDoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
Guest accessYes
DoS attack preventionYes
DMZ supportYes

Protocols

DHCP clientYes
DHCP serverYes
Universal Plug and Play (UPnP)Yes
Supported network protocolsIPv4, IPv6

Design

Product typeTabletop router
Product colourBlack
LED indicatorsLAN, Power, Status, USB, WAN, WLAN
On/off switchYes

Packaging content

Cables includedLAN (RJ-45)
AC adapter includedYes
Quick installation guideYes

Certificates

CertificationCE, FCC, RoHS

Antenna

Antenna designExternal
Antennas quantity3
Transmit powerCE: <20dBm(2.4GHz), <23dBm(5GHz), FCC:<30dBm

Power

Power source typeDC
Output voltage12 V
Output current1.5 A

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C

System requirements

Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows XP
Linux operating systems supportedYes
Mac operating systems supportedmacOS
Mac compatibilityYes

Weight & dimensions

Depth160.6 mm
Height32.7 mm
Width243.5 mm

Packaging data

Package width330 mm
Package depth240 mm
Package height80 mm
Package weight790 g
