Philips CAW7740N/00 wireless router Fast Ethernet Single-band (2.4 GHz) Black, Grey

Philips CAW7740N/00 wireless router Fast Ethernet Single-band (2.4 GHz) Black, Grey

Model CAW7740N/00EAN 8712581377472

69 specifications
  • SpeedWi-Fi 4 (802.11n)
  • TypeTabletop router
  • Weight555 g
  • ColourBlack, Grey
  • Ethernet WANNo
  • Wi-Fi bandSingle-band (2.4 GHz)
See all specifications

Overview

Speed
Wi-Fi 4 (802.11n)
Type
Tabletop router
Weight
555 g
Colour
Black, Grey
Ethernet WAN
No
Wi-Fi band
Single-band (2.4 GHz)
Brand
Philips
Model
CAW7740N/00
Part number
CAW7740N/00
EAN / UPC
8712581377472
Also known as
Philips CAW7740N/00 wireless router Fast Ethernet Single-band (2.4 GHz) Black, Grey

Specifications

69 specifications in 19 groups

WAN connection

Ethernet WANNo
DSL WANYes
SIM card slotNo
3G/4G USB modem compatibilityNo

Wireless LAN features

Wi-Fi bandSingle-band (2.4 GHz)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity13 channels
Modulation16-QAM, 64-QAM, BPSK, CCK, DQPSK, OFDM, QPSK

Network

Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN supportIPSec-ESP Tunnel, L2TP, PPTP
Receiver sensitivity-84 dBm @ 11 Mbps -72 dBm @ 54 Mbps -64 dBm @ 64-QAM -61 dBm @ 64-QAM

Mobile network

3GNo
4GNo

DSL features

ADSLYes

Ports & interfaces

Ethernet LAN (RJ-45) ports4
USB portNo
RJ-11 ports quantity1
Memory card slot(s)No
DC-in jackYes

Management features

Web-based managementYes
Quality of Service (QoS) supportYes
Reset buttonYes
WPS push buttonYes

Security

Security algorithms64-bit WEP, 128-bit WEP, WEP, WPA, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPS
FirewallYes
Firewall securityNetwork Address Port Translation (NAPT)
FilteringYes
MAC address filteringYes
URL filteringYes
DMZ supportYes
Network address translation (NAT)Yes

Protocols

DHCP serverYes
Universal Plug and Play (UPnP)Yes
Routing protocolsRIP-1

Design

Product typeTabletop router
Product colourBlack, Grey
Indication lightYes
On/off switchYes

Packaging content

Cables includedLAN (RJ-45)
AC adapter includedYes
ManualYes
Quick start guideYes

Certificates

CertificationCE, ETS 300 328, ETS 300 836, EN50081, EN50082, EN61000-3-2, EN61000-3-3

Antenna

Antenna designExternal
Antennas quantity2

Features

Plug and PlayYes
Firmware upgradeableYes

Power

Power source typeAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C

System requirements

Windows operating systems supportedWindows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows
Linux operating systems supportedYes
Mac operating systems supportedYes

Weight & dimensions

Depth149 mm
Height39 mm
Weight555 g
Width181 mm

Packaging data

Package width293 mm
Package depth104 mm
Package height194 mm
Package weight917 g
