EA9500-ME wireless router Gigabit Ethernet Tri-band (2.4 GHz
5 GHz / 5 GHz) Black
Model EA9500-ME
37 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypePortable router
- Weight1.73 kg
- ColourBlack
- Ethernet WANYes
- 3GNo
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Portable router
- Weight
- 1.73 kg
- Colour
- Black
- Ethernet WAN
- Yes
- 3G
- No
- Brand
- Linksys
- Category
- Wireless Router
- Model
- EA9500-ME
- Part number
- EA9500-ME
- Also known as
- Linksys EA9500-ME wireless router Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 5 GHz) Black
Specifications
37 specifications in 12 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 5400 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) | 1000 Mbit/s |
| WLAN data transfer rate (second band) | 2166 Mbit/s |
| WLAN data transfer rate (third band) | 2166 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Mobile network
| Specification | Value |
|---|---|
| 3G | No |
| 4G | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 8 |
| USB port | Yes |
Management features
| Specification | Value |
|---|---|
| MU-MIMO technology | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WEP, WPA2-Enterprise |
Design
| Specification | Value |
|---|---|
| Product type | Portable router |
| Product colour | Black |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antennas quantity | 8 |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 1400 MHz |
| Processor cores | 2 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Output voltage | 12 V |
| Output current | 5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 264.5 mm |
| Height | 66.6 mm |
| Weight | 1.73 kg |
| Width | 318.1 mm |
