LevelOne AC1200 Dual Band Wireless Gigabit Router

Model WGR-8031EAN 4015867199374

67 specifications

Memory64 MB
SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
Weight235 g
ColourWhite
Ethernet WANYes

See all specifications

Overview

Memory: 64 MB
Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Weight: 235 g
Colour: White
Ethernet WAN: Yes

Brand: LevelOne
Category: Wireless Router
Model: WGR-8031
Part number: WGR-8031
EAN / UPC: 4015867199374
Also known as: LevelOne AC1200 Dual Band Wireless Gigabit Router

Specifications

67 specifications in 18 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	866 Mbit/s
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	165 channels
Maximum indoor range	50 m

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN support	PPTP, IPSec, L2TP Passthrough

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	No
Memory card slot(s)	No

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, AES, TKIP, WPA, WPA2, WPA2-PSK
Firewall	Yes
MAC address table	20 entries
DMZ support	Yes
Network address translation (NAT)	Yes

Design

Specification	Value
Product type	Tabletop router
Product colour	White
Indication light	Yes
LED indicators	LAN, Power, WAN, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	5 dBi
Antennas quantity	2

Features

Specification	Value
Internal memory	64 MB
Flash memory	8 MB

Power

Specification	Value
Power source type	DC
Output voltage	12 V

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 95%
Storage temperature (T-T)	-20 - 70 °C

Weight & dimensions

Specification	Value
Depth	140 mm
Height	30 mm
Weight	235 g
Width	106 mm

Packaging data

Specification	Value
Package width	145 mm
Package depth	155 mm
Package height	80 mm
Package weight	475 g
Package type	Color Box

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
Country of origin	Taiwan
Master (outer) case width	340 mm
Master (outer) case length	185 mm
Master (outer) case height	434 mm
Master (outer) case gross weight	5.45 kg
Products per master (outer) case	10 pc(s)

Other features

Specification	Value
Frequency band	2.4 ~ 2.4835, 5.15 ~ 5.25, 5.25 ~ 5.825 GHz
Input current	1 A
