LevelOne WBR-6020 wireless router Fast Ethernet

LevelOne WBR-6020 wireless router Fast Ethernet

Model WBR-6020Part no. WBR-6020 NEAN 4015867152904

33 specifications
  • Channels quantity13 channels
  • Ethernet LANYes
  • Ethernet LAN (RJ-45) ports4
  • Antenna gain level (max)2 dBi
  • Operating relative humidity (H-H)0 - 85%
See all specifications

Overview

Channels quantity
13 channels
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
4
Antenna gain level (max)
2 dBi
Operating relative humidity (H-H)
0 - 85%
Brand
LevelOne
Model
WBR-6020
Part number
WBR-6020 N
EAN / UPC
4015867152904
Also known as
LevelOne WBR-6020 wireless router Fast Ethernet

Specifications

33 specifications in 12 groups

Wireless LAN features

Channels quantity13 channels

Network

Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Full duplexYes

Ports & interfaces

Ethernet LAN (RJ-45) ports4

Management features

Web-based managementYes
Quality of Service (QoS) supportYes

Security

Security algorithms128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA, WPA2
FilteringYes
MAC address filteringYes
Network address translation (NAT)Yes

Protocols

DHCP clientYes

Design

Indication lightYes
LED indicatorsYes

Certificates

CertificationCE, FCC

Antenna

Antenna gain level (max)2 dBi
Antennas quantity2

Power

Power over Ethernet (PoE)Yes

Operational conditions

Operating relative humidity (H-H)0 - 85%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C

Other features

Compatible operating systemsWindows 2000, XP, Vista Mac OS X Linux
Compliance industry standardsIEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11i, IEEE 802.1x, IEEE 802.11e, IEEE 802.3x, IEEE 802.3, IEEE 802.3u
Data transfer rate300 Mbit/s
Dimensions (WxDxH)187 x 112 x 29 mm
Frequency range2.4 - 2.4835 GHz
Management platformSNMP
Power requirementsDC 5 V, 2A
Security features- DoS - NAT, SPI - DMZ
WLAN data transfer rates supported300 Mbit/s
Non-operating relative humidity (non-condensing)0 - 95%
