Intellinet 525268 wireless router Fast Ethernet Dual-band (2.4 GHz

Intellinet 525268 wireless router Fast Ethernet Dual-band (2.4 GHz

5 GHz) Grey, White

Model 525268EAN 163120313891

54 specifications

ProcessorRalink RT3352 + Ralink RT3572
SpeedWi-Fi 4 (802.11n)
Weight800 g
ColourGrey, White
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)

See all specifications

Overview

Processor: Ralink RT3352 + Ralink RT3572
Speed: Wi-Fi 4 (802.11n)
Weight: 800 g
Colour: Grey, White
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)

Brand: Intellinet
Category: Wireless Router
Model: 525268
Part number: 525268
EAN / UPC: 163120313891, 151903093450, 151903414323, 523160950072 +1 more
Also known as: Intellinet 525268 wireless router Fast Ethernet Dual-band (2.4 GHz / 5 GHz) Grey, White

Specifications

54 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g
Channels quantity	13 channels

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.3, IEEE 802.3u
VPN support	PPTP, IPSec, L2TP

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WPA-TKIP, WPA2-AES
Firewall	Yes
Filtering	Yes
MAC address filtering	Yes
URL filtering	Yes
DMZ support	Yes
NAT functionality	- Virtual server - Port forwarding - Special applications

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes

Design

Specification	Value
Product colour	Grey, White
LED indicators	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	3 dBi
Antennas quantity	2

Features

Specification	Value
Built-in processor	Yes
Processor model	Ralink RT3352 + Ralink RT3572
Flash memory	4 MB
Plug and Play	Yes

Power

Specification	Value
Output voltage	12 V

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C

Weight & dimensions

Specification	Value
Depth	127 mm
Height	30 mm
Weight	800 g
Width	157 mm

Other features

Specification	Value
Mobile network connection	No
Frequency band	2.4 & 5
Input current	1 A
Rack mounting	No
Supported protocols	CSMA/CA - CSMA/CD - TCP/IP - UDP - ICMP - PPPoE - NTP - NAT - DHCP - DNS
WLAN data transfer rates supported	11,54,300 Mbit/s
