Intellinet 524940 wireless router Fast Ethernet Grey

Intellinet 524940 wireless router Fast Ethernet Grey

Model 524940EAN 766623524940

58 specifications

ProcessorRalink RT3050
Memory16 MB
SpeedWi-Fi 4 (802.11n)
Weight215 g
ColourGrey
Ethernet WANYes

See all specifications

Overview

Processor: Ralink RT3050
Memory: 16 MB
Speed: Wi-Fi 4 (802.11n)
Weight: 215 g
Colour: Grey
Ethernet WAN: Yes

Brand: Intellinet
Category: Wireless Router
Model: 524940
Part number: 524940
EAN / UPC: 766623524940, 086000202491, 182682285385, 872182713524 +1 more
Also known as: Intellinet 524940 wireless router Fast Ethernet Grey

Specifications

58 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes

Wireless LAN features

Specification	Value
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.3u
VPN support	PPTP, IPSec
Receiver sensitivity	- 11n (150 Mbps) MCS0-07: 20 MHz: -73 dBm; 40 MHz: -68 dBm - 11g (54 Mbps) OFDM: -76 dBm - 11b (11 Mbps) CCK: -91 dBm

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
DC-in jack	Yes

Management features

Specification	Value
Web-based management	No
Quality of Service (QoS) support	Yes
Reset button	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-TKIP, WPA2
DoS attack prevention	Yes
Filtering	Yes
MAC address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Management protocols	CSMA
Data link protocols	DHCP, DNS
Supported network protocols	PPTP, L2TP, PPoE, DHCP, NTP, UDP, TCP/IP, CSMA/CA, CSMA/CD, ICMP

Design

Specification	Value
Product colour	Grey
Indication light	Yes
LED indicators	LAN, Link, Power, USB, WLAN, Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45), USB
AC adapter included	Yes
Manual	Yes

Certificates

Specification	Value
Certification	FCC, CE

Antenna

Specification	Value
Antenna gain level (max)	3 dBi
Antennas quantity	1

Features

Specification	Value
Built-in processor	Yes
Processor model	Ralink RT3050
Internal memory	16 MB
Flash memory	4 MB

Power

Specification	Value
Power consumption (typical)	3.5 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	10 - 40 °C
Storage temperature (T-T)	-20 - 60 °C

Weight & dimensions

Specification	Value
Weight	215 g

Other features

Specification	Value
Data transfer rate	150 Mbit/s
Dimensions (WxDxH)	157 x 127 x 30 mm
Frequency range	2.4 - 2.483 GHz
Input current	1 A
Input voltage	12 V
Networking features	Fast Ethernet
Operating temperature (T-T)	50 - 104 °F
USB ports quantity	1
WLAN data transfer rates supported	1,2,6,9,12,24,36,48,54,150 Mbit/s
xDSL connection	No
