Intellinet 524636 wireless router Fast Ethernet Black

Intellinet 524636 wireless router Fast Ethernet Black

Model 524636EAN 766623524636

50 specifications

Speed802.11g
Weight800 g
ColourBlack
Ethernet WANYes
Ethernet LAN (RJ-45) ports4
Antenna gain level (max)2 dBi

See all specifications

Overview

Speed: 802.11g
Weight: 800 g
Colour: Black
Ethernet WAN: Yes
Ethernet LAN (RJ-45) ports: 4
Antenna gain level (max): 2 dBi

Brand: Intellinet
Category: Wireless Router
Model: 524636
Part number: 524636
EAN / UPC: 766623524636
Also known as: Intellinet 524636 wireless router Fast Ethernet Black

Specifications

50 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes

Wireless LAN features

Specification	Value
Top Wi-Fi standard	802.11g
Wi-Fi standards	802.11b, 802.11g
Channels quantity	11 channels
Modulation	16-QAM, 64-QAM, BPSK, DPSK, DSSS, QPSK

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.1D, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
VPN support	PPTP, L2TP, IPsec

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4

Management features

Specification	Value
Web-based management	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, WEP, WPA, WPA-AES, WPA-TKIP, WPA2
Filtering	Yes
MAC address filtering	Yes
DMZ support	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes
Supported network protocols	CSMA/CA, CSMA/CD, TCP/IP, UDP, ICMP, PPPoE, NTP, DNS

Design

Specification	Value
Product colour	Black
LED indicators	LAN, Link, Power, Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Manual	Yes

Certificates

Specification	Value
Certification	FCC, CE, RoHS

Antenna

Specification	Value
Antenna gain level (max)	2 dBi
Antennas quantity	1

Features

Specification	Value
Built-in processor	Yes
Processor model	Realtek RTL8186 + Realtek RTL8225
Firmware upgradeable	Yes

Power

Specification	Value
Power consumption (typical)	5.5 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C

Weight & dimensions

Specification	Value
Weight	800 g

Other features

Specification	Value
Bandwidth	2.412 GHz
Cable length	1 m
Dimensions (WxDxH)	157 x 127 x 30 mm
Frequency range	2.412 - 2.484GHz
Indoor range	100m
Input current	1 A
Input voltage	12 V
Networking features	Fast Ethernet
Operating temperature (T-T)	32 - 104 °F
Outdoor range	300m
WLAN data transfer rates supported	1,2,5.5,6,9,11,12,18,24,36,48,54 Mbit/s
xDSL connection	No
