FRITZ!Box 7690 International
Model FRITZ!Box 7690 InternationalPart no. 20003079EAN 4023125030796
47 specifications
- SpeedWi-Fi 7 (802.11be)
- TypeTabletop router
- Weight657 g
- ColourWhite
- Ethernet WANYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Overview
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Tabletop router
- Weight
- 657 g
- Colour
- White
- Ethernet WAN
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Brand
- FRITZ!
- Category
- Wireless Router
- Model
- FRITZ!Box 7690 International
- Part number
- 20003079
- EAN / UPC
- 4023125030796
- Also known as
- Box FRITZ! 7690 International wireless router 2.5 Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
Specifications
47 specifications in 14 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 5760 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.3bz |
| Automatic channel selection | Yes |
| Dynamic DNS (DDNS) | Yes |
DSL features
| Specification | Value |
|---|---|
| ADSL2+ | Yes |
| VDSL | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| RJ-11 ports quantity | 2 |
| DC-in jack | Yes |
Management features
| Specification | Value |
|---|---|
| Wake-on-LAN ready | Yes |
| Intelligent Mesh technology | Yes |
| WPS push button | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2, WPA3 |
| Network address translation (NAT) | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP server | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Tabletop router |
| Product colour | White |
| Indication light | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DSL, LAN (RJ-45) |
| AC adapter included | Yes |
| Quick start guide | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
| Antenna type | 4x4 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power consumption (typical) | 13 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 184 mm |
| Height | 48 mm |
| Weight | 657 g |
| Width | 250 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 305.5 mm |
| Package depth | 69 mm |
| Package height | 240 mm |
| Package weight | 1.06 kg |
| Package type | Box |
