FRITZ!Box 7530 AX

FRITZ!Box 7530 AX

Model FRITZ!Box 7530 AXPart no. 20002944EAN 4023125029448

51 specifications

SpeedWi-Fi 6 (802.11ax)
TypeTabletop router
ColourWhite
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Ethernet LAN (RJ-45) ports4

See all specifications

Overview

Speed: Wi-Fi 6 (802.11ax)
Type: Tabletop router
Colour: White
Ethernet WAN: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN (RJ-45) ports: 4

Brand: FRITZ!
Category: Wireless Router
Model: FRITZ!Box 7530 AX
Part numbers: 20002944, 20002930
EAN / UPC: 4023125029448, 4023125029301, 4023125029929
Also known as: Box FRITZ! 7530 AX wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White

Specifications

51 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2400 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)	1800 Mbit/s
WLAN data transfer rate (second band)	600 Mbit/s

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Automatic channel selection	Yes
Dynamic DNS (DDNS)	Yes
USB sharing	Yes
VPN support	IPSec

Mobile network

Specification	Value
3G	Yes
4G	No
5G	No

DSL features

Specification	Value
ADSL	Yes
VDSL	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Wake-on-LAN ready	Yes
Intelligent Mesh technology	Yes
MIMO	Yes
MU-MIMO technology	No

Security

Specification	Value
Security algorithms	WPA2, WPA3
Firewall	Yes
Guest access	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes

Design

Specification	Value
Product type	Tabletop router
Product colour	White
Wall mountable	Yes
Indication light	Yes

Packaging content

Specification	Value
Cables included	DSL, LAN (RJ-45)
AC adapter included	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	Internal

Features

Specification	Value
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	DC
Power consumption (typical)	6 W

Weight & dimensions

Specification	Value
Depth	37 mm
Height	150 mm
Width	208 mm

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
