FRITZ!Box 7530
Model FRITZ!Box 7530Part no. 20002839EAN 4023125028397
47 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypeTabletop router
- ColourBlack, Red, White
- Ethernet WANYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- 3GNo
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Tabletop router
- Colour
- Black, Red, White
- Ethernet WAN
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- 3G
- No
- Brand
- FRITZ!
- Category
- Wireless Router
- Model
- FRITZ!Box 7530
- Part number
- 20002839
- EAN / UPC
- 4023125028397
- Also known as
- Box FRITZ! 7530 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black, Red, White
Specifications
47 specifications in 15 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 866 Mbit/s |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (first band) | 866 Mbit/s |
| WLAN data transfer rate (second band) | 400 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Mobile network
| Specification | Value |
|---|---|
| 3G | No |
| 4G | No |
DSL features
| Specification | Value |
|---|---|
| ADSL | Yes |
| VDSL | Yes |
| DSL specification | DSL router with firewall / NAT, DHCP server, DynDNS client, UPnP AV |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| RJ-11 ports quantity | 1 |
| Memory card slot(s) | No |
| DC-in jack | Yes |
Management features
| Specification | Value |
|---|---|
| MIMO | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2, WPS |
| Firewall | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Supported network protocols | IPv6 |
Design
| Specification | Value |
|---|---|
| Product type | Tabletop router |
| Product colour | Black, Red, White |
| Wall mountable | Yes |
| LED indicators | DSL, Power, WLAN |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DSL, LAN (RJ-45) |
| AC adapter included | Yes |
| Quick start guide | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (typical) | 6 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 150 mm |
| Height | 37 mm |
| Width | 208 mm |
Packaging data
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
