FRITZ!Box 6860 5G v2
Model FRITZ!Box 6860 5G v2Part no. 20003182EAN 4023125031823
49 specifications
- SpeedWi-Fi 6 (802.11ax)
- SIM card slotYes
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Mobile network generation5G
- Ethernet LAN (RJ-45) ports1
- Security algorithmsWPA2, WPA3
Overview
- Speed
- Wi-Fi 6 (802.11ax)
- SIM card slot
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Mobile network generation
- 5G
- Ethernet LAN (RJ-45) ports
- 1
- Security algorithms
- WPA2, WPA3
- Brand
- FRITZ!
- Category
- Wireless Router
- Model
- FRITZ!Box 6860 5G v2
- Part number
- 20003182
- EAN / UPC
- 4023125031823
- Also known as
- Box FRITZ! 6860 5G v2 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz)
Specifications
49 specifications in 13 groups
WAN connection
| Specification | Value |
|---|---|
| SIM card slot | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 600 Mbit/s |
| WLAN data transfer rate (second band) | 2400 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.3at, IEEE 802.1Q |
| Port forwarding | Yes |
| VPN Passthrough | Yes |
| VPN support | IPSec and WireGuard, VPN passthrough |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | 5G |
| 3G standards | UMTS, HSPA+ |
| 4G standard | LTE-A |
| 5G standard | Sub6 SA, Sub6 NSA |
| 3G bands supported | 2100,850,900 MHz |
| 4G bands supported | 2000,3800,2400 MHz |
| SIM card type | NanoSIM |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Wake-on-LAN ready | Yes |
| MIMO | Yes |
| Number of data streams | 2x2 |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2, WPA3 |
| Firewall | Yes |
| Firewall security | SPI firewall, DoS protection |
| Guest access | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Schedule access | Yes |
| DoS attack prevention | Yes |
| Parental control | Yes |
| Filtering | Yes |
| URL filtering | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
Design
| Specification | Value |
|---|---|
| Wall mountable | Yes |
| International Protection (IP) code | IP54 |
| Indication light | Yes |
Features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| Power consumption (typical) | 6.8 W |
| Power over Ethernet (PoE) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 31 mm |
| Height | 111 mm |
| Width | 163 mm |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Germany |
