N3 N300 Wireless Router
Model N3Part no. DH-N3EAN 6923172560100
58 specifications
- SpeedWi-Fi 4 (802.11n)
- TypeTabletop router
- Weight125 g
- ColourBlack
- Ethernet WANYes
- Wi-Fi bandSingle-band (2.4 GHz)
Overview
- Speed
- Wi-Fi 4 (802.11n)
- Type
- Tabletop router
- Weight
- 125 g
- Colour
- Black
- Ethernet WAN
- Yes
- Wi-Fi band
- Single-band (2.4 GHz)
- Brand
- Dahua Technology
- Category
- Wireless Router
- Model
- N3
- Part number
- DH-N3
- EAN / UPC
- 6923172560100
- Also known as
- Dahua Technology N3 N300 Wireless Router
Specifications
58 specifications in 16 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| Channels quantity | 13 channels |
| Channel bandwidth | 40 MHz |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Port forwarding | Yes |
| Automatic channel selection | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | No |
| DC-in jack | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| WPS push button | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA-PSK, WPA2-PSK |
| DMZ support | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Tabletop router |
| Product colour | Black |
| Indication light | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Manual | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna design | External |
| Antenna gain level (max) | 3 dBi |
| Antennas quantity | 2 |
| Antenna direction type | Omni-directional |
Features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 0.5 A |
| Power consumption (typical) | 3.2 W |
| External power adapter | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 172 mm |
| Height | 33 mm |
| Weight | 125 g |
| Width | 121 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 245 mm |
| Package depth | 218 mm |
| Package height | 45 mm |
| Package weight | 303 g |
| Number of products included | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Frequency range | 2.412 - 2.484 GHz |
