Dahua Technology AC12 AC1200 Wireless Router

Dahua Technology

AC12 AC1200 Wireless Router

Model AC12Part no. DH-AC12EAN 6923172557315

67 specifications

Memory64 MB
SpeedWi-Fi 5 (802.11ac)
TypeTabletop router
Weight310 g
ColourBlack
Ethernet WANYes

See all specifications

Overview

Memory: 64 MB
Speed: Wi-Fi 5 (802.11ac)
Type: Tabletop router
Weight: 310 g
Colour: Black
Ethernet WAN: Yes

Brand: Dahua Technology
Category: Wireless Router
Model: AC12
Part number: DH-AC12
EAN / UPC: 6923172557315
Also known as: Dahua Technology AC12 AC1200 Wireless Router

Specifications

67 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Channels quantity	165 channels
Channel bandwidth	80 MHz

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Automatic channel selection	Yes
Dynamic DNS (DDNS)	Yes
VPN Passthrough	Yes
Receiver sensitivity	5GHz 11ac VHT80_MCS0: -89dbm 11ac VHT80_MCS9:-62dbm 2.4GHz 11n HT20_MCS0: -95dbm 11n HT20_MCS7: -75dbm 11n HT40_MCS0: -92dbm 11n HT40_MCS7: -72dbm

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Quality of Service (QoS) support	Yes
MIMO	Yes
MU-MIMO technology	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WEP, WPA, WPA2
Parental control	Yes
System event log	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP client	Yes
DHCP server	Yes

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
Wall mountable	Yes
Indication light	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Manual	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antenna gain level (max)	5 dBi
Antennas quantity	4

Features

Specification	Value
Internal memory	64 MB
Number of simultaneously connected devices (max)	32
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	DC
Output voltage	12 V
Output current	1 A
Power consumption (typical)	12 W
External power adapter	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	0 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	20 - 70 °C

Weight & dimensions

Specification	Value
Depth	222 mm
Height	188.4 mm
Weight	310 g
Width	147.4 mm

Packaging data

Specification	Value
Package width	260 mm
Package depth	300 mm
Package height	70 mm
Number of products included	1 pc(s)

Other features

Specification	Value
Bandwidth (first)	2.484 GHz
Bandwidth (second)	5.85 GHz
