ASUS RT-AX56U wireless router Gigabit Ethernet Dual-band (2.4 GHz

RT-AX56U wireless router Gigabit Ethernet Dual-band (2.4 GHz

5 GHz) Black

Model RT-AX56UPart no. 90IG05B0-BA1H0VEAN 4718017485326

78 specifications

Memory512 MB
SpeedWi-Fi 6 (802.11ax)
TypeTabletop router
Weight456 g
ColourBlack
Ethernet WANYes

See all specifications

Overview

Memory: 512 MB
Speed: Wi-Fi 6 (802.11ax)
Type: Tabletop router
Weight: 456 g
Colour: Black
Ethernet WAN: Yes

Brand: ASUS
Category: Wireless Router
Model: RT-AX56U
Part numbers: 90IG05B0-BA1H0V, 90IG05B0-BO3H00, 90IG05B0-BU2H00
EAN / UPC: 4718017485326, 4718017435581, 192876437728, 4718017435611
Also known as: ASUS RT-AX56U wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

78 specifications in 16 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	1201 Mbit/s
High power	Yes

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Printer server	Yes
VPN server	PPTP Server, OpenVPN Server, IPSec server
VPN support	IPSec server PPTP server OpenVPN server PPTP client L2TP client OpenVPN client

Mobile network

Specification	Value
3G	No
4G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Memory card slot(s)	No
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Bandwidth control	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	IPSec, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPS
Firewall	Yes
Firewall security	SPI intrusion detection, DoS protection
Guest access	Yes
DoS attack prevention	Yes
Parental control	Yes
Filtering	Yes
URL filtering	Yes
System event log	Yes

Protocols

Specification	Value
Universal Plug and Play (UPnP)	Yes
Management protocols	UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
LED indicators	LAN, Power, WAN, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Warranty card	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	2

Features

Specification	Value
Built-in processor	Yes
Processor frequency	1500 MHz
Processor cores	4
Internal memory	512 MB
Flash memory	256 MB
Firmware upgradeable	Yes

Power

Specification	Value
Power source type	AC, DC
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Output voltage	12 V
Output current	2 A
External power adapter	Yes

System requirements

Specification	Value
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Android, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Mac compatibility	Yes

Weight & dimensions

Specification	Value
Depth	129.3 mm
Height	47.5 mm
Weight	456 g
Width	223.5 mm

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
