ASUS GS-AX3000 AiMesh

GS-AX3000 AiMesh

Model GS-AX3000 AiMeshPart no. 90IG06K0-MO3R10EAN 4711081173786

75 specifications

Memory512 MB
SpeedWi-Fi 6 (802.11ax)
TypeTabletop router
Weight700 g
ColourBlack
Ethernet WANYes

See all specifications

Overview

Memory: 512 MB
Speed: Wi-Fi 6 (802.11ax)
Type: Tabletop router
Weight: 700 g
Colour: Black
Ethernet WAN: Yes

Brand: ASUS
Category: Wireless Router
Model: GS-AX3000 AiMesh
Part numbers: 90IG06K0-MO3R10, 90IG06K0-MU9R10
EAN / UPC: 4711081173786, 195553004664, 4711081173793
Also known as: ASUS GS-AX3000 AiMesh wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

Specifications

75 specifications in 17 groups

WAN connection

Specification	Value
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	Yes
WAN connection type	RJ-45

Wireless LAN features

Specification	Value
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2976 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Modulation	1024-QAM

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Port forwarding	Yes
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Built-in FTP server	Yes
VPN server	IPSec, OVPN, PPTP

Mobile network

Specification	Value
3G	No
4G	No
5G	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Bandwidth control	Yes
Quality of Service (QoS) support	Yes
Wake-on-LAN ready	Yes
Reset button	Yes
WPS push button	Yes

Security

Specification	Value
Security algorithms	SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA3, WPA3-PSK, WPS
Firewall	Yes
Parental control	Yes
MAC address filtering	Yes
MAC address table	64 entries
URL filtering	Yes
System event log	Yes
DMZ support	Yes

Protocols

Specification	Value
DHCP server	Yes

Design

Specification	Value
Product type	Tabletop router
Product colour	Black
LED indicators	Power, WAN, WLAN
On/off switch	Yes

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
AC adapter included	Yes
Warranty card	Yes
Quick start guide	Yes

Antenna

Specification	Value
Antenna design	External
Antennas quantity	4

Features

Specification	Value
Built-in processor	Yes
Processor frequency	1500 MHz
Processor cores	3
Internal memory	512 MB
Flash memory	256 MB
Works with Amazon Alexa	Yes

Power

Specification	Value
Power source type	AC
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Output voltage	12 V
Output current	2 A

Operational conditions

Specification	Value
Operating relative humidity (H-H)	50 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90%
Storage temperature (T-T)	0 - 70 °C

Weight & dimensions

Specification	Value
Depth	180 mm
Height	166 mm
Weight	700 g
Width	268 mm

Packaging data

Specification	Value
Package width	320 mm
Package depth	300 mm
Package height	105 mm
Package weight	1.36 kg
Number of products included	1 pc(s)

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
