ASUS DSL-N12U wireless router Fast Ethernet Black, Silver

ASUS DSL-N12U wireless router Fast Ethernet Black, Silver

Model DSL-N12UPart no. DSL-N12U_BEAN 5711045819537

52 specifications

Memory32 MB
SpeedWi-Fi 4 (802.11n)
Weight345 g
ColourBlack, Silver
DSL WANYes
Ethernet LAN (RJ-45) ports4

See all specifications

Overview

Memory: 32 MB
Speed: Wi-Fi 4 (802.11n)
Weight: 345 g
Colour: Black, Silver
DSL WAN: Yes
Ethernet LAN (RJ-45) ports: 4

Brand: ASUS
Category: Wireless Router
Model: DSL-N12U
Part numbers: DSL-N12U_B, DSL-N12U, 90-IG1P002M10-3PA0
EAN / UPC: 5711045819537, 4719543346570, 886227026623, 4716659026624 +3 more
Also known as: ASUS DSL-N12U wireless router Fast Ethernet Black, Silver

Specifications

52 specifications in 17 groups

WAN connection

Specification	Value
DSL WAN	Yes

Wireless LAN features

Specification	Value
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-95dBm@1Mbps -92dBm@11Mbps -75dBm@54Mbps -72dBm@72.2Mbps -68dBm@150Mbps

DSL features

Specification	Value
ADSL2+	Yes
DSL specification	ANSI T1.413 Issue 2, ITU-T G.992.1 Annex A (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.994.1 (G.hs), ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.5 Annex A/M

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	4
RJ-11 ports quantity	1
DC-in jack	Yes

Management features

Specification	Value
Web-based management	Yes
Reset button	Yes

Security

Specification	Value
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA-PSK, WPA2-PSK, WPS
Stateful Packet Inspection (SPI)	Yes
Filtering	Yes
MAC address filtering	Yes
Network address translation (NAT)	Yes

Protocols

Specification	Value
DHCP server	Yes
Universal Plug and Play (UPnP)	Yes

Design

Specification	Value
Product colour	Black, Silver
LED indicators	DSL, LAN, Power, WLAN

Packaging content

Specification	Value
Cables included	LAN (RJ-45), Phone (RJ-11)
AC adapter included	Yes
Quick start guide	Yes

Certificates

Specification	Value
Certification	CE, FCC, IC, IDA, NCC, PCT, Wi-Fi

Antenna

Specification	Value
Antenna gain level (max)	5 dBi
Antennas quantity	2
Transmit power	15 dBmW

Features

Specification	Value
Internal memory	32 MB
Flash memory	8 MB
Firmware upgradeable	Yes

Power

Specification	Value
Power consumption (typical)	18 W

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-10 - 50 °C
Storage relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-40 - 60 °C

Weight & dimensions

Specification	Value
Weight	345 g

Other features

Specification	Value
Downstream data rate	24 Mbit/s
Frequency range	2.4 GHz
Input frequency	50/60 Hz
Input voltage	100 - 240 V
Power requirements	12 V, 1.5 A
Security features	Port, IP, URL
USB ports quantity	1
WLAN data transfer rates supported	1,2,6,9,11,12,18,24,36,48,54,300 Mbit/s
xDSL connection	Yes
