ASUS DSL-N12E C1

ASUS DSL-N12E C1

Model DSL-N12E C1Part no. 90IG0101-BM3000EAN 4053162744356

56 specifications
  • Memory32 MB
  • SpeedWi-Fi 4 (802.11n)
  • Weight314 g
  • ColourBlack
  • DSL WANYes
  • 3GNo
See all specifications

Overview

Memory
32 MB
Speed
Wi-Fi 4 (802.11n)
Weight
314 g
Colour
Black
DSL WAN
Yes
3G
No
Brand
ASUS
Model
DSL-N12E C1
Part number
90IG0101-BM3000
EAN / UPC
4053162744356, 4716659624189, 4719543388914
Also known as
ASUS DSL-N12E C1 wireless router Fast Ethernet Black

Specifications

56 specifications in 18 groups

WAN connection

DSL WANYes

Wireless LAN features

Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity13 channels

Network

Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN supportIPSec, PPTP, L2TP

Mobile network

3GNo
4GNo

DSL features

ADSL2+Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports4
RJ-11 ports quantity1
DC-in jackYes

Management features

Web-based managementYes
Reset buttonYes

Security

Security algorithms128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
System event logYes

Protocols

Supported network protocolsIPv4, IPv6

Design

Product colourBlack
LED indicatorsDSL, LAN, Power, WAN, WLAN
On/off switchYes

Packaging content

Cables includedLAN (RJ-45), Phone (RJ-11)
AC adapter includedYes
ManualYes
Quick start guideYes

Antenna

Antenna designExternal
Antenna gain level (max)5 dBi
Antennas quantity2
Detachable antenna(s)No

Features

Internal memory32 MB
Flash memory8 MB
Firmware upgradeableYes

Power

Power source typeDC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating relative humidity (H-H)5 - 59%
Operating temperature (T-T)-10 - 50 °C
Storage relative humidity (H-H)5 - 95%
Storage temperature (T-T)-40 - 60 °C

System requirements

Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supportedYes
Mac operating systems supportedYes

Weight & dimensions

Depth123 mm
Height35 mm
Weight314 g
Width190 mm

Other features

Mobile network connectionNo
Downstream data rate24 Mbit/s
Frequency band2.4 GHz
Rack mountingNo
WLAN data transfer rates supported1,2,5.5,6,9,11,12,18,24,36,48,300 Mbit/s
xDSL connectionYes
