2x2 HDMI Video Wall Controller - 4K
60Hz HDMI 2.0 Video Input to 4x 1080p Output - Video Wall Processor for Multi Screen Display - Video Wall Split
Model ST124HDVWEAN 065030883603
41 specifications
- Weight1 kg
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- AC input voltage100 - 240 V
- Width165 mm
Overview
- Weight
- 1 kg
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- AC input voltage
- 100 - 240 V
- Width
- 165 mm
- Brand
- StarTech.com
- Category
- Video Switch
- Model
- ST124HDVW
- Part number
- ST124HDVW
- EAN / UPC
- 065030883603
- Also known as
- StarTech.com 2x2 HDMI Video Wall Controller - 4K 60Hz HDMI 2.0 Video Input to 4x 1080p Output - Video Wall Processor for Multi Screen Display - Video Wall Split
Specifications
41 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI version | 2.0 |
| HDMI in | 1 |
| Number of HDMI outputs | 4 |
| USB port type | USB Type-A |
| RJ-45 input ports | 1 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| Extended display identification data (EDID) | Yes |
| Audio output channels | 7.1 channels |
| HDCP | Yes |
| HDCP version | 2.2 |
| LED indicators | Yes |
| Maximum refresh rate | 60 Hz |
| Supported graphics resolutions | 4096 x 2160 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC adapter input current | 1 A |
| AC adapter output voltage | 24 V |
| AC adapter output current | 1.25 A |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, REACH |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 165 mm |
| Depth | 230 mm |
| Height | 45 mm |
| Weight | 1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 263 mm |
| Package depth | 302 mm |
| Package height | 70 mm |
| Package weight | 1.6 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 318 mm |
| Master (outer) case length | 550 mm |
| Master (outer) case height | 380 mm |
| Products per master (outer) case | 10 pc(s) |
