4K 4-Port HDMI Multiviewer Switch, Switch with Four Inputs on One Display, 4k@30Hz, Multiple Viewing Options Including Picture-in-Picture and Dual/Qua
Model 208406EAN 766623208406
46 specifications
- Weight372 g
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- Power consumption (typical)5 W
- Width85 mm
Overview
- Weight
- 372 g
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- Power consumption (typical)
- 5 W
- Width
- 85 mm
- Brand
- Manhattan
- Category
- Video Switch
- Model
- 208406
- Part number
- 208406
- EAN / UPC
- 766623208406
- Also known as
- Manhattan 4K 4-Port HDMI Multiviewer Switch, Switch with Four Inputs on One Display, 4k@30Hz, Multiple Viewing Options Including Picture-in-Picture and Dual/Qua
Specifications
46 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 5 |
| HDMI in | 4 |
| Number of HDMI outputs | 1 |
| USB port type | Micro USB Type-B |
| Digital audio optical out | 1 |
| 3.5 mm (1/8-inch) out | Yes |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| 3D | Yes |
| Audio output channels | 7.1 channels |
| Bandwidth | 10.2 Gbit/s |
| Bandwidth | 340 MHz |
| Cable length | 1 m |
| External power adapter | Yes |
| HD type | 4K Ultra HD |
| HDCP | Yes |
| HDCP version | 1.4 |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1600p, 2160p |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 85 mm |
| Depth | 198 mm |
| Height | 19 mm |
| Weight | 372 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 196 mm |
| Package depth | 212 mm |
| Package height | 55 mm |
| Package weight | 671 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Batteries included | Yes |
| Cables included | USB Type-A to Micro USB Type-B, USB Type-A to USB Type-C |
| Manual | Yes |
| Mounting brackets included | Yes |
| Remote control included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS, UKCA, Federal Communications Commission (FCC) |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 456 mm |
| Master (outer) case length | 620 mm |
| Master (outer) case height | 212 mm |
| Master (outer) case net weight | 14.8 kg |
| Products per master (outer) case | 20 pc(s) |
