Switching Presentation Scaler
Model 38282EAN 4002888382823
34 specifications
- Weight1.22 kg
- ColourBlack
- Video port typeHDMI/VGA/DisplayPort
- MaterialMetal
- Width230 mm
- Operating temperature (T-T)-10 - 40 °C
Overview
- Weight
- 1.22 kg
- Colour
- Black
- Video port type
- HDMI/VGA/DisplayPort
- Material
- Metal
- Width
- 230 mm
- Operating temperature (T-T)
- -10 - 40 °C
- Brand
- Lindy
- Category
- Video Switch
- Model
- 38282
- Part number
- 38282
- EAN / UPC
- 4002888382823
- Also known as
- Lindy Switching Presentation Scaler
Specifications
34 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI/VGA/DisplayPort |
| HDMI ports quantity | 2 |
| HDMI version | 1.4 |
| HDMI in | 2 |
| VGA (D-Sub) ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 1 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| Consumer Electronics Control (CEC) support | Yes |
| Extended display identification data (EDID) | Yes |
| Bandwidth | 10.2 Gbit/s |
| HDCP | Yes |
| HDCP version | 2.2 |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160 |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, REACH |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 23.6 mm |
| Height | 100 mm |
| Weight | 1.22 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 418 mm |
| Package depth | 82 mm |
| Package height | 253 mm |
| Package weight | 1.59 kg |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -15 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
