8x8 HDMI 10.2G Matrix Switch
Model 38153EAN 4002888381536
38 specifications
- Weight2.5 kg
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- AC adapter output voltage12 V
- Width440 mm
Overview
- Weight
- 2.5 kg
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- AC adapter output voltage
- 12 V
- Width
- 440 mm
- Brand
- Lindy
- Category
- Video Switch
- Model
- 38153
- Part number
- 38153
- EAN / UPC
- 4002888381536
- Also known as
- Lindy 8x8 HDMI 10.2G Matrix Switch
Specifications
38 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 16 |
| HDMI in | 8 |
| Number of HDMI outputs | 8 |
| RJ-45 input ports | 1 |
| RS-232 ports | 1 |
| Video in | 8 |
| Video out | 8 |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| 3D | Yes |
| Bandwidth | 297 MHz |
| Colour depth | 48 bit |
| Digital horizontal frequency | 30 - 60 kHz |
| Dolby technologies | DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD |
| External power adapter | Yes |
| HD type | 4K Ultra HD |
| HDCP | Yes |
| LED indicators | Yes |
| Rack capacity | 1U |
| Remote control type | IR, RS-232 |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 12 V |
| AC adapter output current | 2.5 A |
| Power consumption (typical) | 23 W |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, UKCA, FCC, RoHS, REACH & California Proposition 65 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 200 mm |
| Height | 45 mm |
| Weight | 2.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| AC adapter included | Yes |
| Cables included | RS-232 |
| Manual | Yes |
| Mounting brackets included | Yes |
| Remote control included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
