VS481A-AT-U video switch HDMI
Model VS481A-AT-U
29 specifications
- Weight470 g
- ColourSilver
- Video port typeHDMI
- MaterialMetal
- Width200 mm
- Operating temperature (T-T)0 - 50 °C
Overview
- Weight
- 470 g
- Colour
- Silver
- Video port type
- HDMI
- Material
- Metal
- Width
- 200 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- ATEN
- Category
- Video Switch
- Model
- VS481A-AT-U
- Part number
- VS481A-AT-U
- Also known as
- ATEN VS481A-AT-U video switch HDMI
Specifications
29 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 4 |
| HDMI in | 1 |
| Number of HDMI outputs | 4 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Silver |
| 3D | Yes |
| Bandwidth | 225 MHz |
| Bandwidth | 6.75 Gbit/s |
| HD type | Full HD |
| HDCP | Yes |
| Input impedance | 100 Ω |
| Maximum operating distance | 15 m |
| Output impedance | 100 Ω |
| Plug and Play | Yes |
| Supported video modes | 1080p |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 82.7 mm |
| Height | 25 mm |
| Weight | 470 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | HDMI |
| User guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
