VS481A video switch HDMI
Model VS481AEAN 6727921158682
33 specifications
- Weight470 g
- ColourBlack, Silver
- Video port typeHDMI
- MaterialMetal
- Power consumption (typical)2.4 W
- Compliance certificatesRoHS
Overview
- Weight
- 470 g
- Colour
- Black, Silver
- Video port type
- HDMI
- Material
- Metal
- Power consumption (typical)
- 2.4 W
- Compliance certificates
- RoHS
- Brand
- ATEN
- Category
- Video Switch
- Model
- VS481A
- Part number
- VS481A
- EAN / UPC
- 6727921158682, 151903624968, 163120473427, 617407496512 +6 more
- Also known as
- ATEN VS481A video switch HDMI
Specifications
33 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI in | 4 |
| Number of HDMI outputs | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DisplayPorts quantity | 0 |
| Audio (L/R) in | 0 |
| Audio (L/R) out | 0 |
| Digital audio coaxial in | 0 |
| Digital audio coaxial out | 0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Component video (YPbPr/YCbCr) out | 0 |
| BNC input ports | 0 |
| BNC output ports | 0 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black, Silver |
| External power adapter | Yes |
| LED indicators | Yes |
| Maximum operating distance | 20 m |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA) |
| Supported video modes | 1080i, 1080p, 480p, 720p |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.4 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 470 g |
| Dimensions (WxDxH) | 200 x 80 x 25 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | HDMI |
| Manual | Yes |
| Quick start guide | Yes |
| Remote control included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
