3-Port True 4K HDMI Switch
Model VS381BEAN 672792012198
33 specifications
- Weight150 g
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- Power consumption (typical)1.46 W
- Width71.6 mm
Overview
- Weight
- 150 g
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- Power consumption (typical)
- 1.46 W
- Width
- 71.6 mm
- Brand
- ATEN
- Category
- Video Switch
- Model
- VS381B
- Part number
- VS381B
- EAN / UPC
- 672792012198, 4710469340383
- Also known as
- ATEN 3-Port True 4K HDMI Switch
Specifications
33 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 4 |
| HDMI in | 3 |
| Number of HDMI outputs | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| 3D | Yes |
| Bandwidth | 18 Gbit/s |
| Bandwidth | 600 MHz |
| Dolby technologies | Dolby Vision |
| External power adapter | Yes |
| HD type | 4K Ultra HD |
| HDCP | Yes |
| HDCP version | 2.2 |
| Input impedance | 100 Ω |
| Maximum operating distance | 5 m |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 4096 x 2160 pixels |
| Plug and Play | Yes |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 1.46 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71.6 mm |
| Depth | 79 mm |
| Height | 25.5 mm |
| Weight | 150 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
