ATEN VS381
Model VS381Part no. VS381-ATEAN 672792003844
29 specifications
- Weight70 g
- ColourBlack
- Video port typeHDMI
- MaterialPlastic
- Power consumption (typical)3 W
- Width51.2 mm
Overview
- Weight
- 70 g
- Colour
- Black
- Video port type
- HDMI
- Material
- Plastic
- Power consumption (typical)
- 3 W
- Width
- 51.2 mm
- Brand
- ATEN
- Category
- Video Switch
- Model
- VS381
- Part number
- VS381-AT
- EAN / UPC
- 672792003844, 4710423778818, 5037374450075, 5054629710937
- Also known as
- ATEN AT-VS381
Specifications
29 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 4 |
| HDMI in | 3 |
| Number of HDMI outputs | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Plastic |
| Product colour | Black |
| Full HD | Yes |
| HDCP | Yes |
| LED indicators | Yes |
| Maximum resolution | 1920 x 1200 pixels |
| Plug and Play | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Supported video modes | 1080i, 1080p, 480p, 720p |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 3 W |
| Power requirements | 5V DC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 51.2 mm |
| Depth | 96 mm |
| Height | 22.4 mm |
| Weight | 70 g |
| Dimensions (WxDxH) | 51.2 x 96 x 22.4 mm |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Remote control included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Connector type | Type A Female |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
